卡特零件查询（SE50） 467-4575: SHOE GP-CUTOFF
广数供应链运营团队, 18 02月, 2025，浏览：
516 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4B-6493 | [1] | SPRING-ROD | |
| 2. | 6S-6646 | [2] | PIN-COTTER | |
| 3. | 232-4810 | [1] | PIN | |
| 4. | 320-2845 | [1] | LEVER | |
| 5. | 467-3360 | [1] | MOUNT AS | |
| | 8T-3597M | [2] | NUT-WELD(M12X1.75-THD) | |
| 6. | 467-4026 | [1] | TUBE | |
| 7. | 467-4082 | [2] | PLATE-LOCK | |
| 8. | 467-4145 | [1] | BRACKET AS | |
| | 127-5447 | [1] | SPACER(10.5X20X12-MM THK) | |
| 9. | 8T-4223 | [2] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 10. | 8T-4779M | [2] | BOLT(M16X2X35-MM) | |
| 11. | 8T-7971 | [2] | WASHER-HARD(13.5X25.5X5-MM THK) | |
| 12. | 9F-4684 | [2] | PIN | |
| 13. | 9X-8257 | [2] | WASHER(17.5X30X3.5-MM THK) | |
| | M | | METRIC PART |
