| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 3S-2093 | [2] | STRAP-CABLE | |
| 2. | 177-2215 | [6] | STRAP-DUAL CLAMP | |
| 3. | 327-0325 | [2] | STRAP-CABLE | |
| 4. | 132-5789 | [1] | CLIP(LADDER) | |
| 5. | 438-1058 | [7] | HARNESS AS-SENSOR(HYDRAULIC CYLINDER) | |
| 6. | 438-1059 | [2] | HARNESS AS-SENSOR(CYLINDER, SCREED EXTENDER) | |
| (EACH HARNESS AS INCLUDES) | ||||
| 9X-3401 | [3] | PIN-CONNECTOR(16-GA TO 18-GA) | ||
| 176-9299 | [1] | KIT-RECEPTACLE(3-PIN) | ||
| (INCLUDES RECEPTACLE AS & WEDGE) | ||||
| 7. | 7K-1181 | [12] | STRAP-CABLE | |
