卡特零件查询（434F2） 468-7975: KIT-CONTROL VALVE
广数供应链运营团队, 18 02月, 2025，浏览：
812 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8T-5381 | [2] | PIN AS-SPRING | |
| 2. | 164-1399 | [2] | KNOB | |
| 3. | 164-1435 | [2] | PLATE | |
| 4. | 170-6312 | [4] | BEARING | |
| 5. | 390-7515 | [1] | TOWER AS | |
| | 159-9541M | [2] | NUT-WELD(M10X1.5-THD) | |
| 6. | 391-1293 | [1] | SHAFT | |
| 7. | 391-5422 | [1] | LEVER AS(LH) | |
| 7A. | 164-1436 | [1] | BEARING | |
| 8. | 391-5423 | [1] | LEVER AS(RH) | |
| 8A. | 164-1436 | [1] | BEARING | |
| 9. | 398-8074 | [1] | ROD AS | |
| 10. | 418-8515 | [1] | ROD AS | |
| | 435-7651 | [1] | BALL JOINT | |
| | 446-8059 | [1] | ROD | |
| | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| | 8T-5063 | [1] | ROD END | |
| 11. | 418-8517 | [2] | ROD AS | |
| | | | (EACH INCLUDES) |
| | 391-2709 | [1] | ROD AS | |
| | 435-7651 | [1] | BALL JOINT | |
| | 8T-4133M | [1] | NUT(M10X1.5-THD) | |
| 12. | 426-0313 | [1] | SEAL | |
| 13. | 430-9927 | [1] | FILM-IDENTIFICATION(EXCAVATOR CONTROL) | |
| 14. | 437-3580 | [4] | MOUNT | |
| 15. | 439-3492 | [1] | ROD AS | |
| | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| | 8T-5063 | [1] | ROD END | |
| | 435-7651 | [1] | BALL JOINT | |
| | 439-3493 | [1] | ROD | |
| 16. | 439-3495 | [4] | PIN | |
| 17. | 439-3496 | [2] | BRACKET AS | |
| | | | (EACH INCLUDES) |
| 17A. | 385-6511 | [2] | BUSHING | |
| 18. | 439-4932 | [1] | ROD AS | |
| 19. | 440-3614 | [1] | BOSS | |
| 20. | 454-0097 | [2] | CLIP | |
| 21. | 164-1402 | [2] | SLEEVE | |
| 22. | 164-1404 | [2] | SPACER(10.67X16.95X23-MM THK) | |
| 23. | 189-5358M | [4] | BOLT(M10X1.5X60-MM) | |
| 24. | 5C-2890M | [6] | NUT(M6X1-THD) | |
| 25. | 6V-3964 | [1] | WASHER-HARD(8.8X25.5X5-MM THK) | |
| 26. | 6V-9824 | [3] | RING-RETAINING | |
| 27. | 7X-2537M | [1] | BOLT(M8X1.25X35-MM) | |
| 28. | 7X-7729 | [10] | WASHER(11X25X3-MM THK) | |
| 29. | 8T-0389M | [10] | LOCKNUT(M10X1.5-THD) | |
| 30. | 8T-4121 | [10] | WASHER-HARD(11X21X2.5-MM THK) | |
| 31. | 8T-4133M | [4] | NUT(M10X1.5-THD) | |
| 32. | 8T-4138M | [6] | BOLT(M6X1X20-MM) | |
| 33. | 8T-4172M | [2] | BOLT(M10X1.5X80-MM) | |
| 34. | 8T-4205 | [6] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 35. | 8T-4222 | [4] | WASHER-PLATED(11X32X2.5-MM THK) | |
| 36. | 8T-4224 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| 37. | 8T-4908M | [1] | BOLT(M8X1.25X25-MM) | |
| 38. | 8T-6466M | [2] | BOLT(M10X1.5X60-MM) | |
| 39. | 9R-2807 | [4] | CLIP(RETAINER) | |
| | M | | METRIC PART |
