久保田零件查询H23503 HYDRAULIC OUTLET BLOCK [HST TYPE] [ROPS TYPE] HYDRAULIC SYSTEMEPC Kubota online
广数供应链运营团队, 18 02月, 2025，浏览：
922 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
TD06037500
|
[1] |
ASSY BLOCK FRONT HYD
|
2.7390(lbs); 1.245
|
| 020. |
TD06037610
|
[1] |
CAP HYD.BLOCK
|
0.3080(lbs); 0.140
|
| 030. |
0481706400
|
[1] |
O RING
|
0.0066(lbs); 0.003
|
| 040. |
0481705170
|
[1] |
O RING
|
0.0044(lbs); 0.002
|
| 050. |
0112350828
|
[4] |
BOLT
|
0.0308(lbs); 0.014
|
| 060. |
3135137910
|
[1] |
PLUG
|
0.1210(lbs); 0.055
|
| 070. |
3135137920
|
[1] |
SPRING RELIEF
|
0.0440(lbs); 0.020
|
| 080. |
3135137930
|
[1] |
SEAT RELIEF VALVE
|
0.0352(lbs); 0.016
|
| 090. |
3135137940
|
[1] |
POPPET
|
0.0110(lbs); 0.005
|
| 100. |
3135137950
|
[5] |
SHIM
|
0.0022(lbs); 0.001
|
| 100. |
3135137960
|
[2] |
SHIM
|
0.0022(lbs); 0.001
|
| 100. |
3135137970
|
[2] |
SHIM
|
0.0022(lbs); 0.001
|
| 110. |
0401360050
|
[2] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 120. |
0481110160
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 130. |
TA04037590
|
[2] |
CUSHION
|
0.0132(lbs); 0.006
|
| 140. |
0112350830
|
[2] |
BOLT
|
0.0330(lbs); 0.015
|
| 140. |
0112750830
|
[2] |
BOLT
|
0.0506(lbs); 0.023
|
| 150. |
TA04037600
|
[2] |
COLLAR
|
0.0198(lbs); 0.009
|
| 150. |
3599902550
|
[2] |
COLLAR
|
0.0198(lbs); 0.009
|
| 170. |
TD06056460
|
[1] |
COMP.PIPE RETURN
|
0.9130(lbs); 0.415
|
| 180. |
6659136250
|
[1] |
JOINT
|
0.1760(lbs); 0.080
|
| 190. |
6711137180
|
[2] |
GASKET
|
0.0066(lbs); 0.003
|
| 200. |
0601251533
|
[1] |
JOINT PIPE
|
0.1452(lbs); 0.066
|
| 210. |
0481700140
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
