久保田零件查询F14500 PTO CLUTCH LEVER SPEED CHANGE SHIFT FORK /SHIFT LEVEREPC Kubota online
广数供应链运营团队, 18 02月, 2025，浏览：
612 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
3F76027800
|
[1] |
BRACKET PTO LEVER
|
0.7920(lbs); 0.360
|
| 020. |
0276360080
|
[2] |
NUT FLANGE
|
0.0110(lbs); 0.005
|
| 030. |
3F76027812
|
[1] |
LEVER PTO
|
0.1650(lbs); 0.075
|
| 040. |
3691927820
|
[1] |
GRIP PTO LEVER
|
0.0330(lbs); 0.015
|
| 050. |
3325129630
|
[1] |
SPRING
|
0.0286(lbs); 0.013
|
| 060. |
0401560080
|
[1] |
WASHER PLAIN
|
0.0220(lbs); 0.010
|
| 070. |
0551150215
|
[1] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
| 080. |
3F76027740
|
[1] |
WIRE PTO
|
0.4400(lbs); 0.200
|
| 090. |
0401250060
|
[2] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 100. |
0551151612
|
[2] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
