Comprehensive Guide to Caterpillar 320D Excavator Fault Codes

Understanding the fault codes of your Caterpillar 320D excavator is crucial for efficient maintenance and troubleshooting. This detailed guide, brought to you by Growshine International, provides a comprehensive list of fault codes for both the Engine (MID:036) and the Machine (MID:039).

Engine MID: 036 Fault Codes

Machine MID: 039 Fault Codes

Event Codes and Conditions

Failure Mode Identifier (FMI)

Additional Machine ECM Codes

This section lists ECM codes for various Caterpillar excavator models, including 300D, 345C, 365C, and 385C.

• 39 Machine ECM (300D: B4M1)

• 105 Machine ECM (345C: STD Controller)

• 39 Machine ECM (365C, 385C; ABL2C+)

• 36 Engine ECM (ADEM)

• 106 Attachment Controller (345C: ATT Controller)

• 30 Monitor

• 124 MSS

• 122 Product Link

Component Codes (CID)

• 4 + 8V DC Power Supply

• 91 Throttle Position Sensor

• 96 Fuel Level Sensor

• 100 Engine Oil Pressure Sensor

• 110 Engine Coolant Temperature Sensor

• 145 +12V DC Power Supply

• 167 Alternator Charging Voltage Sensor

• 168 Electrical System Voltage

• 171 Atmospheric Temperature Sensor

• 190 Engine Speed Sensor

• 246 CAN Data Link

• 247 SAEJ1939 Data Link

• 248 CAT Data Link

• 1969 Boom Cylinder Head End Pressure Sensor

• 3012 Boom Cylinder Retract Pilot Pressure Sensor

• 3572 Swing Pilot Pressure Sensor

• 3573 Pump 1 Reverse Flow Control Pressure Reducing Pressure Sensor

• 3574 Pump 2 Reverse Flow Control Pressure Reducing Pressure Sensor

• 253 Personality Module

• 254 Electronic Control Module

• 262 5V Sensor DC Power Supply

• 263 Digital Sensor Power Supply (8V or 12V)

• 268 Programmable Parameter Error

• 271 Alarm Horn

• 291 Engine Cooling Fan Solenoid Valve

• 295 Large Hydraulic Excavator Control Module

• 324 Alarm Lamp (Action)

• 362 Engine Fan Speed Control Solenoid Valve

• 374 Swing Brake Solenoid Valve

• 376 Travel Alarm

• 379 Machine Auto Lubrication Pressure Sensor

• 466 Left Travel Control Pedal Position Sensor

• 467 Right Travel Control Pedal Position Sensor

• 485 Auto Reversing Fan Solenoid Valve

• 544 Engine Cooling Fan Speed Sensor

• 545 Ether Injection Control Relay

• 558 Auto Lubrication Relay

• 581 Power Shift Solenoid Valve

• 583 Boom Lift Solenoid Valve

• 586 Engine Speed Dial Switch

• 587 Engine Governor Position Sensor

• 558 Monitoring System Display

• 590 Engine Control Module

• 598 Travel Speed Solenoid Valve

• 600 Hydraulic Oil Temperature Sensor

• 732 Fine Swing Solenoid Valve

• 735 Lifting Mode Solenoid Valve

• 790 Swing Pump (Output) Pressure Sensor

• 799 Service Tool

• 864 Hydraulic Pump Pressure Sensor

• 1073 VIDS Display Module

• 1118 Mid-Position Flow Bypass Solenoid Valve

• 1119 Boom Drift Prevention Valve

• 1120 Stick Drift Prevention Valve

• 1121 Front System High Pressure Solenoid Valve

• 1124 Anti-Theft Solenoid Valve

• 1125 Left Joystick Fore/Aft Position Sensor

• 1126 Left Joystick Left/Right Position Sensor

• 1127 Right Joystick Fore/Aft Position Sensor

• 1128 Right Joystick Left/Right Position Sensor

• 1129 Right Attachment Pedal Sensor

• 1130 Left Attachment Pedal Sensor

• 1131 Joystick 1# Switch

• 1132 Joystick 4# Switch

• 1138 Boom Cylinder Rod End Retract Solenoid Valve

• 1139 Stick Cylinder Rod End Extend Solenoid Valve

• 1140 Stick Cylinder Rod End Retract Solenoid Valve

• 1141 Bucket Cylinder Rod End Extend Solenoid Valve

• 1142 Bucket Cylinder Rod End Retract Solenoid Valve

• 1143 Right Swing Solenoid Valve

• 1144 Left Swing Solenoid Valve

• 1145 Attachment Extend Solenoid Valve

• 1146 Attachment Retract Solenoid Valve

• 1147 Medium Pressure Circuit 1# A Solenoid Valve

• 1148 Medium Pressure Circuit 1# B Solenoid Valve

• 1149 Boom Lowering Check/Adjustment Solenoid Valve

• 1150 Swing Pump Swash Plate Angle Solenoid Valve

• 1155 Implement Pump Power Shift Pressure Solenoid Valve

• 1159 Stick Lowering Check/Adjustment Solenoid Valve

• 1160 Hydraulic Lock Solenoid Valve

• 1161 Front Pump Pressure Sensor

• 1162 Rear Pump Pressure Sensor

• 1163 Left Travel Rearward Solenoid Valve

• 1164 Right Travel Rearward Solenoid Valve

• 1165 Right Travel Forward Solenoid Valve

• 1166 Left Travel Forward Solenoid Valve

• 1178 Machine Overload Alarm Pressure Sensor

• 1191 Main Hydraulic Valve

• 1192 Swing Valve

• 1193 Boom Cylinder Rod End Extend Solenoid Valve

• 1522 Relief Valve 2# Pilot Valve Solenoid

• 1523 Relief Valve 1# Pilot Valve Solenoid

• 1525 Straight Travel Solenoid Valve

• 1590 Main Pump Flow Limit Pressure Solenoid Valve

• 1591 Negative Flow Control Stable Pressure Sensor

• 1593 Attachment 1# Extend Pressure Solenoid Valve

• 1594 Attachment 2# Extend Pressure Solenoid Valve

• 1595 Attachment 3# Extend Pressure Solenoid Valve

• 1596 Attachment 1# Extend Retract Solenoid Valve

• 1597 Attachment 2# Extend Retract Solenoid Valve

• 1598 Attachment 3# Extend Retract Solenoid Valve

• 1609 F2 Type Valve Load Sensing Pressure Sensor

• 1615 One-Way/Two-Way Valve Solenoid Valve

• 1657 Left Joystick Thumb Wheel

• 1658 Right Joystick Thumb Wheel

• 1659 F1 Type Valve Load Sensing Pressure Sensor

• 1660 Left Pump Negative Flow Control Pressure Solenoid Valve

• 1661 Right Pump Negative Flow Control Pressure Solenoid Valve

• 1662 F1 Type Valve Flow Solenoid Valve

• 1663 4# Attachment Valve Extend Solenoid Valve

• 1664 4# Attachment Valve Retract Solenoid Valve

• 1665 1# Relief Valve Pressure Solenoid Valve

• 1666 2# Relief Valve Pressure Solenoid Valve

• 1680 Right Pump Bypass to Tank Solenoid Valve

• 1688 Left Pump Negative Flow Control Pressure Sensor

• 1689 Right Pump Negative Flow Control Pressure Sensor

• 1849 Engine Fan Reverse Relay

• 1931 Auxiliary Circuit Flow Solenoid Valve

• 2265 1# Hydraulic Pump Output Pressure Sensor

• 2266 2# Hydraulic Pump Output Pressure Sensor

• 2280 Travel Alarm Relay

• 2300 Switch Panel

Additional Failure Mode Identifier (FMI) Codes

• 0 Data Valid But Above Normal

• 1 Data Valid But Below Normal

• 2 Data Erratic, Intermittent, or Incorrect

• 3 Voltage Above Normal or Shorted

• 4 Voltage Below Normal or Shorted

• 5 Current Below Normal or Open

• 6 Current Above Normal or Grounded

• 7 Mechanical System Not Responding

• 8 Abnormal Frequency, Pulse Width, or Period

• 9 Abnormal Update

• 10 Abnormal Speed or Rate of Change

• 11 Not Identifiable

• 12 Bad Device or Component

• 13 Out of Calibration

Additional Event Codes (E)

• E096 Fuel Pressure High

• E162 Intake Pressure High

• E198 Fuel Pressure Low

• E256 Emergency Shutdown Switch Pressed

• E360 Oil Pressure Low

• E361 Engine Coolant Temperature High

• E362 Engine Overspeed

• E390 Fuel Filter Blocked

• E539 Intake Temperature Too High
