Understanding and Resolving Hitachi Excavator Faults
Encountering faults is an inevitable part of operating Hitachi excavators. This comprehensive analysis helps users understand and address these issues, covering sensor anomalies and system problems, and providing guidance on troubleshooting and resolution. For users to better grasp and handle these malfunctions, we offer a thorough breakdown of Hitachi excavator fault codes. These codes encompass various aspects, including sensor malfunctions and systemic issues, delivering complete information for fault diagnosis and repair solutions.
Detailed Breakdown of Fault Codes
Below is a detailed table of Hitachi excavator fault codes, translated for your convenience. Growshine International is a leading exporter of engineering machinery parts, heavy truck parts, agricultural machinery parts, and auto parts, ready to support your needs.
| Fault Code (英文) | Fault Code (中文) | Problem Description (英文) | Problem Description (中文) |
|---|---|---|---|
| 1100-2 | 1100-2 | Engine speed abnormal | 发动机转速异常 |
| 11101-3 | 11101-3 | Engine speed control knob sensor high voltage abnormal | 发动机转速控制旋钮传感器高压异常 |
| 11101-4 | 11101-4 | Engine speed control knob sensor low voltage abnormal | 发动机转速控制旋钮传感器低压异常 |
| 11200-3 | 11200-3 | Pump 1 oil delivery pressure sensor high voltage abnormal | 泵1输油压力传感器高压异常 |
| 11200-4 | 11200-4 | Pump 1 oil delivery pressure sensor low voltage abnormal | 泵1输油压力传感器低压异常 |
| 651-3 | 651-3 | Nozzle #1 drive system open circuit, injector 1 monitor no input signal | 喷嘴#1 驱动系统开路，喷油器1监控器无输入信号 |
| 652-3 | 652-3 | Nozzle #2 drive system open circuit, injector 2 monitor no input signal | 喷嘴#2 驱动系统开路，喷油器2监控器无输入信号 |
| 653-3 | 653-3 | Nozzle #3 drive system open circuit, injector 3 monitor no input signal | 喷嘴#3 驱动系统开路，喷油器3监控器无输入信号 |
| 654-3 | 654-3 | Nozzle #4 drive system open circuit, injector 4 monitor no input signal | 喷嘴#4 驱动系统开路，喷油器4监控器无输入信号 |
| 655-3 | 655-3 | Nozzle #5 drive system open circuit, injector 5 monitor no input signal | 喷嘴#5 驱动系统开路，喷油器5监控器无输入信号 |
| 656-3 | 656-3 | Nozzle #6 drive system open circuit, injector 6 monitor no input signal | 喷嘴#6 驱动系统开路，喷油器6监控器无输入信号 |
| 157-0 | 157-0 | Common rail pressure abnormal (level 1), pressure exceeds 185 MPa | 共用油槽压力异常（一级），压力超过185 MPa |
| 157-0 | 157-0 | Common rail pressure abnormal (level 2), level 1 abnormal and pressure exceeds 190 MPa | 共用油槽压力异常（二级），一级异常且压力超过190 MPa |
| 157-2 | 157-2 | Common rail pressure abnormal (pump overpressure), actual rail pressure is 40 MPa higher than target | 共用油槽压力异常（泵超压），实际油槽压力比目标高40 MPa |
| 633-7 | 633-7 | Pressure limiter opened | 压力限制器打开 |
| 1240-1 | 1240-1 | No pressure supplied to pump (fuel leak), actual rail pressure is 50 MPa higher than target | 无压力输送到泵（燃油泄漏），实际油槽压力比目标高50 MPa |
| 1239-1 | 1239-1 | No pressure supplied to pump (fuel leak), actual rail pressure is 15 MPa | 无压力输送到泵（燃油泄漏），实际油槽压力为15 MPa |
For a complete list of fault codes, please refer to the full Hitachi excavator fault code table. These cover various engine and pump related issues, including abnormal engine speed and pump oil delivery pressure. Remember Growshine International for your excavator parts needs!
Typical Faults and Troubleshooting
1. Swing Pilot Pressure Sensor Anomaly
Fault Code: 11301-3
Problem: Swing Pilot Pressure Sensor High Voltage Abnormal
Cause: Voltage reaches or exceeds 4.75V
Affected Controls:
Boom regeneration control
Attachment flow control
Swing alarm control
Machine Symptoms:
Slow boom movement when combining boom retract and swing operations.
If the machine is equipped with a swing alarm that is activated, the alarm will sound continuously.
Troubleshooting:
Check the wiring harness connections.
Replace the swing pilot pressure sensor (回转先导压力传感器).
Fault Code: 11301-4
Problem: Swing Pilot Pressure Sensor Low Voltage Abnormal
Cause: Voltage is below 0.25V
Affected Controls:
Boom regeneration control
Attachment flow control
Swing alarm control
Machine Symptoms:
Slow boom movement when combining boom retract and swing operations.
If the machine is equipped with a swing alarm that is activated, the alarm will sound continuously.
Troubleshooting:
Check the wiring harness connections.
Replace the swing pilot pressure sensor (回转先导压力传感器).
2. Boom Lift Pilot Pressure Sensor Anomaly
Fault Code: 11301-3
Problem: Boom Lift Pilot Pressure Sensor High Voltage Abnormal
Cause: Voltage reaches or exceeds 4.75V
Affected Controls:
HP mode control
Boom regeneration control
Excavation regeneration control
Automatic power boost control
Attachment flow control
Machine Symptoms:
Boom lifting speed cannot be increased in HP mode.
Boom speed becomes slow when performing combined boom lift and arm retract operations.
Troubleshooting:
Check the wiring harness connections.
Replace the boom lift pilot pressure sensor (动臂提升先导压力传感器).
Fault Code: 11301-4
Problem: Boom Lift Pilot Pressure Sensor Low Voltage Abnormal
Cause: Voltage is below 0.25V
Affected Controls:
HP mode control
Boom regeneration control
Excavation regeneration control
Automatic power boost control
Attachment flow control
Machine Symptoms:
Boom lifting speed cannot be increased in HP mode.
Boom speed becomes slow when performing combined boom lift and arm retract operations.
Troubleshooting:
Check the wiring harness connections.
Replace the boom lift pilot pressure sensor (动臂提升先导压力传感器).
