凯斯零件查询(3440) - CASE IH ROUND BALER (1/87-12/87) (06) - LAMPS AND LIGHTING HARNESS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1009 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZA708451
|
[3] |
BRACKET
|
IH
- lamp
|
| 2. |
ZA707964
|
[1] |
TERMINAL CONNECTOR,14 - 16
|
IH
TERMINAL - butt splice
|
| 3. |
ZA103734
|
[1] |
LIGHT
|
CAS
LAMP ASSEMBLY - tail, red
|
| 4. |
9417866
|
[1] |
BULB,C6, #1156, 12.8V
|
IH
- lamp, no. 1156 Superseded by part number: 529068
|
| 5. |
ZA103735
|
[2] |
LIGHT
|
CAS
LAMP ASSEMBLY - flasher, amber Superseded by part number: ZA708294
|
| 7. |
291207C1
|
[1] |
CLAMP
|
IH
STRAP - tie Superseded by part number: 529070
|
| 8. |
299614C1
|
[3] |
CLAMP
|
IH
- tube Superseded by part number: 515-25127
|
| 9. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
WIRE - 14 gauge (Cut from bulk roll 995055R1)
|
| . . |
995055R1
|
[1] |
CABLE
|
IH
WIRE - 14 gauge, 100 foot (30 M) roll
|
| 10. |
ZA104936
|
[1] |
HARNESS
|
CAS
- lighting
|
| . . |
997130R2
|
[1] |
CABLE
|
IH
- 3 conductor, 14 gauge, 100 foot (30 M) roll
|
| 12. |
598803R1
|
[6] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5, Full Thd
|
IH
BOLT - round head square neck, 5/16 NC x 1 inch Superseded by part number: 88992
|
| 13. |
80681
|
[6] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 14. |
120376
|
[6] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
