沃尔沃零件查询2001; 2001B; 2001AG; 2001BG; 2002; 2002B; 2002D; 2002AG; 2002BG; 2003; 2003B; 2003D; 2003AG; 2003BG; 2003T; 2003TB; 2003 SOLAS; 2003B SOLAS; 2003TCooling SystemSea Water Pump with Installation Components: BEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
396 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
858150
|
[1] |
Sea water pump
|
|
| 2. |
925093
|
[1] |
O-ring
|
|
| 3. |
858526
|
[1] |
Gear
|
|
| 4. |
914446
|
[1] |
Snap ring
|
|
| 5. |
418411
|
[1] |
Sealing ring
|
|
| 6. |
955894
|
[2] |
Washer
|
|
| 7. |
955295
|
[1] |
Hexagon screw
|
L=20mm
|
| 7. |
955303
|
[1] |
Hexagon screw
|
L=65mm
|
| 8. |
418411
|
[1] |
Sealing ring
|
|
| 9. |
955303
|
[1] |
Hexagon screw
|
L=65mm
|
| 10. |
860474
|
[1] |
Coolant pipe
|
|
| 11. |
961665
|
[4] |
Hose clamp
|
|
| 12. |
858505
|
[1] |
Hose
|
|
| 13. |
840948
|
[1] |
Coolant pipe
|
|
| 14. |
858162
|
[1] |
Sea-water pipe
|
Reverse gear-sea water pump, See group 4A
|
| 15. |
952629
|
[1] |
Clamp
|
|
| 16. |
955269
|
[1] |
Hexagon screw
|
|
| 17. |
955781
|
[1] |
Hexagon nut
|
|
