凯斯零件查询(3440) - CASE IH ROUND BALER (1/87-12/87) (20) - TWINE TUBE HYDRAULIC CYLINDER, 1-1/2 INCH (38 MM) BORE X 8" (203MM) STROKE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
988 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
ZA105804
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - twine tube (Cross no. 028052 stamped on body)
|
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
BODY ASSEMBLY - cylinder (Order ZA105804)
|
| 2. |
ZA105810
|
[1] |
NUT
|
CAS
- hex lock, 5/8 inch NF
|
| 3. |
ZA720106
|
[1] |
PISTON
|
CAS
ASSEMBLY - cylinder
|
| 10. |
ZA105807
|
[1] |
RING
|
CAS
- retaining
|
| 11. |
ZA105805
|
[1] |
HEAD
|
CAS
- cylinder
|
| 15. |
ZA105806
|
[1] |
NUT
|
CAS
- retaining, cylinder head
|
| 16. |
ZA105808
|
[1] |
SHAFT
|
CAS
ROD ASSEMBLY - piston
|
| 17. |
ZA105811
|
[1] |
SEAL
|
CAS
- seal, Includes: Ref. 5, 6, 9, 12, 13 and 14
|
