凯斯零件查询(3440) - CASE IH ROUND BALER (1/87-12/87) (28) - WINDGUARD Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
570 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZA105975
|
[1] |
LARGE PLATE
|
CAS
FRAME - windguard, 7 line
|
| 2. |
ZA104921
|
[1] |
BRACKET
|
IH
- windguard, right
|
| 3. |
ZA104922
|
[1] |
BRACKET
|
IH
- windguard, left
|
| 4. |
ZA104749
|
[2] |
PIN
|
IH
- windguard
|
| 5. |
407211R1
|
[2] |
CLIP
|
IH
PIN - hair (Package of 20)
|
| 6. |
17140R1
|
[4] |
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
|
IH
BOLT - round head square neck, 1/2 NC x 1-1/4 inch, grade 1 Superseded by part number: 87868
|
| 7. |
25710R1
|
[2] |
WASHER
|
IH
- flat, hardened Superseded by part number: 86624188
|
| 8. |
120378
|
[4] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
