| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
ZA4830003
|
[1] |
RETAINER ATTACHMENT - crop, 4 foot (1 219 MM) (Machinery item, order 0101041)
|
|
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
RETAINER ASSEMBLY - crop (Order machinery item)
|
| 2. |
ZA104811
|
[1] |
PIN
|
IH
SHAFT ASSEMBLY - stub
|
| 3. |
180181
|
[1] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
IH
- hex, 1/2 NC x 2 inch Superseded by part number: 9706716
|
| 4. |
20704R1
|
[6] |
WASHER
|
IH
- flat, 1-1/32 x 1-1/2 x 7/64 inch (26 x 38 x 3 MM) Superseded by part number: 86624170
|
| 5. |
9413956
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138
|
| 6. |
113-233
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
- hex, 3/8"-16 NC x 1-3/4", grade 5 Superseded by part number: 9706689
|
| 7. |
9413953
|
[1] |
LOCK NUT,3/8"-16, GB
|
IH
NUT - hex lock, 3/8 inch NC Superseded by part number: 231-4136
|
