凯斯零件查询(3440) - CASE IH ROUND BALER (1/87-12/87) (34) - TAILGATE FRAME Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
456 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZA105927
|
[1] |
GUIDE
|
CAS
FRAME ASSEMBLY - tailgate, with decals
|
| 2. |
REF
|
[1] |
INSTRUCTION
|
NH
DECAL - warning, keep away from rear (See Figure 62)
|
| 7. |
ZA104923
|
[1] |
WEDGE
|
IH
- left
|
| 8. |
ZA105914
|
[1] |
SPACER
|
CAS
PIN - bale ejection
|
| 9. |
180122
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
IH
- hex, 3/8 NC x 1 inch Superseded by part number: 113-207
|
| 10. |
ZA104715
|
[1] |
PLATE
|
IH
- mounting
|
| 11. |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT - round head square neck, 3/8 NC x 1 inch, grade 1 Superseded by part number: 88682
|
| 12. |
ZA104716
|
[1] |
STRAP
|
IH
- rubber
|
| 13. |
180124
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
|
| 14. |
118775
|
[2] |
WASHER,3/8" x 13/16" x .065"
|
IH
- flat, 13/32 x 13/16 x 3/64 inch (10 x 21 x 1 MM) Superseded by part number: 87613282
|
| 15. |
ZA105977
|
[1] |
GUARD
|
CAS
- left
|
| 17. |
ZA105976
|
[1] |
GUARD
|
CAS
- right
|
| 19. |
ZA704673
|
[2] |
SPACER
|
IH
- 1/2 ID x 11/32 inch (13 x 9 MM)
|
| 20. |
120390
|
[2] |
WASHER,1/2"
|
IH
- flat, 9/16 x 1-3/8 x 3/32 inch (14 x 35 x 2 MM) Superseded by part number: 106265
|
| 21. |
9413956
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex, 1/2 inch NC Superseded by part number: 231-4138
|
| 22. |
180181
|
[2] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
IH
- hex, 1/2 NC x 2 inch Superseded by part number: 9706716
|
