| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AW26813 | [4] | Screw | (SUB FOR R93127 AND R93128) |
| 2. | R93126 | [1] | Boot | |
| 3. | AW26457 | [1] | Disk Brake Caliper Assy | (IF ORIGINAL CALIPER WITH "GLUE-IN" CABLE IS REPLACED, AW26459 CABLE MUST ALSO BE ORDERED.) (RH BOTTOM PULL) (BOTH RH AND LH CALIPERS IDENTIFIED WITH GREY "HB" LOGO PLUG MUST BE REPLACED; ORDER AW26457 RH CALIPER, AW26458 LH CALIPER AND (2) AW26459 |
| 3. | AW26457 | [1] | Disk Brake Caliper Assy | (IF ORIGINAL CALIPER WITH "GLUE-IN" CABLE IS REPLACED, AW26459 CABLE MUST ALSO BE ORDERED.) |
| 3. | AW26458 | [1] | Disk Brake Caliper Assy | (IF ORIGINAL CALIPER WITH "GLUE-IN" CABLE IS REPLACED, AW26459 CABLE MUST ALSO BE ORDERED.) (LH TOP PULL) (BOTH LH AND RH CALIPERS IDENTIFIED WITH GREY "HB" LOGO PLUG MUST BE REPLACED; ORDER AW26457 RH CALIPER, AW26458 LH CALIPER AND (2) AW26459 CAB |
| 3. | AW26458 | [1] | Disk Brake Caliper Assy | (IF ORIGINAL CALIPER WITH "GLUE-IN" CABLE IS REPLACED, AW26459 CABLE MUST ALSO BE ORDERED.) |
| 4. | W40314 | [1] | Gasket | |
| 5. | R53543 | [1] | O-Ring | |
| 6. | R93129 | [1] | Housing | |
| 7. | RE32921 | [AR] | Bumper | (PACKAGE CONTAINS 4 BUMPERS) |
| 8. | W39563 | [1] | Bracket | (FOR MACHINES PRIOR TO S.N. 3400 (WITH BRACKET, HAYES NO. 12-09705), ALSO ORDER (1) R93129.) |
| 9A. | M86877 | [4] | Bolt | |
| 9B. | R92627 | [4] | Screw | |
| 10. | AM116515 | [AR] | Brake Kit | (PACKAGE CONTAINS 4 PADS) (SUB FOR RE32920) |
| 11. | W40313 | [1] | Clip | |
| 12. | AW26459 | [1] | Cable | (INCLUDES W40313) |
| 13. | 24H1621 | [4] | Washer | 11/32" X 1" X 0.220" |
| ... | R44302 | [AR] | Tie Band |
