凯斯零件查询(3450) - CASE IH ROUND TIE BALER (1/83-12/89) (08) - FLASHING WARNING LIGHTS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
407 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZA708451
|
[3] |
BRACKET
|
IH
- light
|
| 2. |
ZA707964
|
[8] |
TERMINAL CONNECTOR,14 - 16
|
IH
TERMINAL
|
| 3. |
ZA103734
|
[1] |
LIGHT
|
CAS
- tail - (Red)
|
| . . |
9417866
|
[1] |
BULB,C6, #1156, 12.8V
|
IH
-LAMP (No. 1156) Superseded by part number: 529068
|
| 4. |
ZA103735
|
[2] |
LIGHT
|
CAS
- flasher (Amber) Superseded by part number: ZA708294
|
| 5. |
291207C1
|
[12] |
CLAMP
|
IH
TIE - hose Superseded by part number: 529070
|
| 6. |
299614C1
|
[3] |
CLAMP
|
IH
- cable Superseded by part number: 515-25127
|
| 7. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
WIRE - 14GA x 30 FT long (Furnish from 100 ft roll marked 9950555R1 - for 1 ft length)
|
| . . |
995055R1
|
[1] |
CABLE
|
IH
WIRE - 100 foot roll
|
| 8. |
ZA104936
|
[1] |
HARNESS
|
CAS
- lighting
|
| . . |
997130R1
|
[1] |
CABLE
|
IH
WIRE - 100 foot roll Superseded by part number: 997130R2
|
| 10. |
598803R1
|
[6] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5, Full Thd
|
IH
BOLT - round head square neck, 5/16 NC x 1 inch Superseded by part number: 88992
|
| 11. |
80681
|
[6] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 12. |
120376
|
[6] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
