| 1. |
395149R1
|
[1] |
QUICK MALE COUPLING
|
IH
COUPLING ASSEMBLY - poppet type male, 7/8-14 inch (Will work with ISO female coupling but at low efficiency) Superseded by part number: 86615558
|
| 2. |
1272399C2
|
[1] |
QUICK MALE COUPLING
|
IH
COUPLING ASSEMBLY - self sealing male, 7/8 NF Superseded by part number: 86615558
|
| 3. |
544787R91
|
[1] |
COUPLING, BREAK AWAY
|
IH
COUPLING ASSEMBLY - ball type male, 7/8-14 inch (Will not work with ISO female coupling) Superseded by part number: 1341843C1
|
| 4. |
1285718C2
|
[1] |
QUICK MALE COUPLING
|
IH
ASSEMBLY - ISO standard male, 3/4-16 inch
|
| 5. |
364885R1
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
IH
- 5/8 inch OD tube (Used with 7/8-14 inch couplers) Superseded by part number: 167269
|
| 6. |
570828R1
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
IH
- 1/2 inch OD tube (Used with 3/4-16 inch couplers) Superseded by part number: 128825
|
| 7. |
935433R1
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 7/8"-14, O-Ring
|
IH
CONNECTOR - short reducer, 3/8 tube, 9/16-18 x 7/8-14 inch thread (Used with 7/8-14 inch couplers) Superseded by part number: 525646
|
| 8. |
607728R1
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 1/2"-14, NPTF
|
IH
CONNECTOR - reducer, 3/8 tube, 9/16-18 x 1/2-14 inch thread (Used with 3/4-16 inch couplers) (Prior to P.I.N. 000800) Superseded by part number: 19956
|
| 8. |
587639R1
|
[1] |
HYD CONNECTOR,9/16"-18, 37 Degree x 3/4"-18, O-Ring
|
IH
CONNECTOR - short reducer, 3/8 tube, 9/16-18 x 3/4-16 inch thread (Used with 3/4-16 inch couplers) Superseded by part number: 128817
|
| 9. |
407045R1
|
[1] |
FITTING
|
IH
CONNECTOR - 3/4-16 x 7/8-14 inch thread (For use with 7/8-14 couplers) (Used with bale slicer attachment) Superseded by part number: 84323487
|
| 10. |
ZA105663
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR - 3/4-16 to 1/2-14 inch thread (For use with 3/4-16 inch couplers) (Used with bale slicer attachment)
|
