| 1. |
9413956
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex, 1/2 inch NC Superseded by part number: 231-4138
|
| 2. |
ZA104721
|
[1] |
HITCH ASSY
|
IH
HITCH ASSEMBLY
|
| 3. |
96332C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - warning
|
| 4. |
96319C1
|
[1] |
DECAL
|
IH
- caution
|
| 5. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
DECAL - important (Order kit 1265869C93)
|
| 6. |
119522C1
|
[1] |
PIN
|
IH
- klik
|
| 7. |
176868H1
|
[1] |
PIN
|
IH
- klik
|
| 8. |
21214R1
|
[1] |
WASHER
|
IH
- flat, 1-5/32 x 2 x 7/64 inch (29 x 50 x 2 mm) Superseded by part number: 495-81192
|
| 9. |
472790R2
|
[1] |
STUD
|
IH
- lower
|
| 10. |
26076R1
|
[1] |
LOCK NUT,1 1/8"-12, GB
|
IH
NUT - hex, 1-1/8 inch NF Superseded by part number: 231-46118
|
| 11. |
ZA104542
|
[1] |
BAR
|
IH
- hitch extension
|
| 12. |
271730
|
[1] |
SWASH PLATE,Hex, 5/8" - 11 x 3 3/4", Gr 5
|
NNA
- hex, 5/8 NC x 3-3/4 inch Superseded by part number: 413-1060, 413-1060, NLS
|
| 13. |
60863C1
|
[1] |
NUT
|
IH
- hex flange, 5/8 inch NC Superseded by part number: 208778C1
|
| 14. |
ZA104770
|
[1] |
BRACKET
|
IH
- hitch
|
| 15. |
25710R1
|
[1] |
WASHER
|
IH
- flat, 17/32 x 1-1/16 x 1/8 inch (13 x 26 x 3 mm) Superseded by part number: 86624188
|
| 16. |
120390
|
[1] |
WASHER,1/2"
|
IH
- flat, 17/32 x 1-3/8 x 3/32 inch (13 x 34 x 2 mm) Superseded by part number: 106265
|
| 17. |
180177
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
- hex, 1/2 NC x 1-1/2 inch Superseded by part number: 113-410
|
| 18. |
ZA103986
|
[1] |
HOLDER
|
IH
- hose
|
| 19. |
145950C1
|
[1] |
SUPPORT
|
IH
|
| 20. |
148032C1
|
[1] |
NUT,Flg, USR, 1"-8
|
IH
- hex flange, 1 inch NC
|
| 21. |
28425R1
|
[1] |
WASHER
|
IH
- flat, 21/32 x 1-1/2 x 3/16 inch (16 x 38 x 4 mm) Superseded by part number: 86624156
|
| 22. |
271547
|
[1] |
STUD,Hex, 5/8" - 11 x 1 1/2", Gr 5
|
NNA
- hex, 5/8 NC x 1-1/2 inch Superseded by part number: 413-1024, 413-1024, NLS
|
| 23. |
222605C92
|
[1] |
BAR
|
IH
ASSEMBLY
|
| 25. |
180179
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
|
IH
- hex, 1/2 NC x 1-3/4 inch Superseded by part number: 113-412
|
