神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-024) - STARTER (NIKKO) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
632 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 5811001620 | [1] | STATER ASM, 24V-4.5KW | |
| . . | 1811001890 | [1] | STARTER ASM, 24V-4.5KW | |
| . . | VI1811001891 | [1] | STARTER ASM, 24V-4.5KW | |
| 1. | VI1811291850 | [1] | PIN, LEVER, STATER | |
| 2. | VI5811270160 | [1] | LEVER ASM, SHIFT | |
| 2-1. | VI1811270310 | [1] | LEVER ASM, SHIFT | |
| 3. | VI1811291840 | [1] | NUT | |
| 4. | VI5811291470 | [1] | PLATE | KOB Superseded by part number: 289577A1 |
| 5. | VI5811510360 | [1] | SWITCH | KOBSWITCH ASM.MAGNETIC |
| 6. | VI5811291460 | [1] | PLUNGER ASM. | |
| 7. | VI9821161400 | [1] | BUSH, INSULATOR | |
| 8. | VI5811291480 | [1] | CONNECTOR, MOVING | |
| 9. | VI9821161420 | [1] | WASHER, INSULATOR | |
| 10. | VI5811180190 | [1] | HOLDER | |
| 11. | VI5811291490 | [2] | RING.CLIP | |
| 12. | VI5811291500 | [1] | TERMINAL ASM. | |
| 13. | VI5811291510 | [2] | WASHER | |
| 14. | VI5811291520 | [2] | BOLT | |
| 15. | VI5811291420 | [1] | PLUG, DISH | |
| 16. | VI5811230210 | [1] | BRACKET ASM, FRT | |
| 16-1. | VI1811230250 | [1] | BRACKET ASM, FRT | |
| 17. | VI5811291430 | [1] | METAL | |
| 17-1. | VI1811293970 | [1] | METAL | |
| 18. | VI5811291440 | [2] | RING, CLIP | |
| 19. | VI5811291450 | [1] | STOP | KOBSTOPPER, PINION Superseded by part number: 289575A1 |
| 20. | VI5811220160 | [1] | COUPLING | KOBCLUTCH ASM.OVER RUNNING Superseded by part number: 289572A1 |
| 21. | VI5811130320 | [1] | BRACKET, CENTER | |
| 21-1. | VI1811130260 | [1] | BRACKET, CENTER | |
| 21-2. | VI1811130810 | [1] | BRACKET, CENTER | |
| 22. | VI5811230200 | [1] | SHAFT ASM. | |
| 22-1. | VI1811230240 | [1] | SHAFT ASM. | |
| 23. | VI5811291610 | [1] | BEARING, BALL | |
| 23-1. | VI1811293860 | [1] | BEARING ASSY | KOBBEARING, BALL Superseded by part number: VI8944188490, 77271657 |
| 24. | VI5811291600 | [1] | WASHER | |
| 25. | VI5811291590 | [2] | WASHER | |
| 26. | VI5811291580 | [1] | WASHER, INSULATE | |
| 27. | VI5811130330 | [1] | BRACKET, CENTER | |
| 27-1. | VI1811130730 | [1] | BRACKET, CENTER | |
| 27-2. | VI1811130820 | [1] | BRACKET, CENTER | |
| 28. | VI1812291140 | [3] | WASHER | |
| 28-1. | VI1812291140 | [2] | WASHER | |
| 29. | VI5811291570 | [1] | BOLT | |
| 30. | VI5811290240 | [4] | SCREW, DISH | |
| 30-1. | VI5811292210 | [4] | SCREW, DISH | |
| 31. | VI5811160280 | [1] | WIRE ASM., LEAD | |
| 31-1. | VI1811160440 | [1] | WIRE ASM., LEAD | |
| 32. | VI5811291530 | [1] | TERMINAL ASM. | |
| 32-1. | VI1811293840 | [1] | TERMINAL ASM. | |
| 33. | VI5811120190 | [1] | COIL ASM., FIELD | |
| 33-1. | VI1811293960 | [1] | COIL | KOBASM, FIELD |
| 34. | VI5811291560 | [2] | SET OF THRUST WASHER | KOBWASHER |
| 35. | VI5811210260 | [1] | ARMATURE ASM. | |
| 35-1. | VI1811210370 | [1] | FITTING | KOBARMATURE ASM. |
| 36. | VI5811291550 | [1] | BEARING, BALL | |
| 36-1. | VI1811293950 | [1] | BALL BEARING | KOBBEARING, BALL Superseded by part number: 289357A1 |
| 37. | VI1811291960 | [1] | BEARING.BALL | |
| 37-1. | VI1811293850 | [1] | BALL BEARING | KOBBEARING, BALL Superseded by part number: 289353A1 |
| 38. | VI5811150290 | [1] | BRACKET ASM, RR. | |
| 38-1. | VI1811150610 | [1] | BRACKET ASM, RR. | |
| 38-2. | VI1811150690 | [1] | REAR COVER | KOBBRACKET ASM, RR. |
| 39. | VI5811160300 | [2] | BRUSH | KOBASM (-) |
| 39-1. | VI1811160430 | [2] | BRUSH HOLDER | KOBBRUSH ASM (-) Superseded by part number: 289340A1 |
| 40. | VI5811180180 | [1] | HOLDER, BRUSH | |
| 40-1. | VI1811180360 | [1] | HOLDER | KOBHOLDER, BRUSH Superseded by part number: 289343A1 |
| 41. | VI5811150300 | [1] | BRACKET, RR. | |
| 41-1. | VI1811150620 | [1] | BRACKET, RR. | |
| 41-1. | VI1811150700 | [1] | U-BRACKET | KOBBRACKET, RR. |
| 42. | VI5811170140 | [4] | SPRING, BRUSH | |
| 43. | VI5811160290 | [2] | BRUSH ASM (+) | |
| 43-1. | VI1811160420 | [2] | BRUSH HOLDER | KOBBRUSH ASM (+) Superseded by part number: 426186A1 |
| 44. | VI5811291540 | [2] | BOLT | |
| 44-1. | VI5811292140 | [2] | BOLT | |
| 45. | VI1811293870 | [3] | BOLT | |
| 53. | VI5811291690 | [1] | SEAL ASM | |
| 53-1. | VI1811293940 | [1] | SEAL ASM. | |
| 53-2. | VI1811294380 | [1] | SEAL ASM. | |
| 54. | VI1811294390 | [1] | CAP, GUM | |
