神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-025) - STARTER (NIKKO) (P/N-581100-1770) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
753 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5811001770 | [1] | STARTER ASM, 24V-4.5KW | |
| 1. | VI1811291850 | [1] | PIN, LEVER | |
| 2. | VI5811270160 | [1] | LEVER ASM, SHIFT | |
| 3. | VI1811291840 | [1] | NUT | |
| 4. | VI5811291470 | [1] | PLATE | KOB Superseded by part number: 289577A1 |
| 5. | VI5811510360 | [1] | SWITCH | KOBSWITCH ASM, MAGNETIC |
| 6. | VI5811291460 | [1] | PLUNGER ASM. | |
| 7. | VI9821161400 | [1] | BUSH, INSULATE | |
| 8. | VI5811291480 | [1] | CONNECTOR, MOVING | |
| 9. | VI9821161420 | [1] | WASHER, INSULATOR | |
| 10. | VI5811180190 | [1] | HOLDER | |
| 11. | VI5811291490 | [2] | RING, CLIP | |
| 12. | VI5811291500 | [1] | TERMINAL ASM. | |
| 13. | VI5811291510 | [2] | WASHER | |
| 14. | VI5811291520 | [2] | BOLT | |
| 15. | VI5811291420 | [1] | PLUG, DISH | |
| 16. | VI5811230210 | [1] | BRACKET ASM, FRT | |
| 17. | VI5811291430 | [1] | METAL | |
| 18. | VI5811291440 | [2] | RING, CLIP | |
| 19. | VI5811291450 | [1] | STOP | KOBSTOPPER, PINION Superseded by part number: 289575A1 |
| 20. | VI5811220160 | [1] | COUPLING | KOBCLUTCH ASM. Superseded by part number: 289572A1 |
| 21. | VI5811130320 | [1] | BRACKET, CENTER | |
| 22. | VI5811230200 | [1] | SHAFT ASM. | |
| 23. | VI5811291610 | [1] | BEARING.BALL | |
| 24. | VI5811291600 | [1] | WASHER | |
| 25. | VI5811291590 | [2] | WASHER | |
| 26. | VI5811291580 | [1] | WASHER, INSULATER | |
| 27. | VI1811180310 | [1] | BRACKET, CENTER | |
| 28. | VI1812291140 | [3] | WASHER | |
| 29. | VI5811291570 | [1] | BOLT | |
| 30. | VI5811290240 | [4] | SCREW, DISH | |
| 31. | VI5811160280 | [1] | WIRE ASM, LEAD | |
| 32. | VI5811291530 | [1] | TERMINAL ASM. | |
| 33. | VI5811120190 | [1] | COIL ASM, FIELD | |
| 34. | VI5811291560 | [2] | SET OF THRUST WASHER | KOBWASHER |
| 35. | VI5811210260 | [1] | ARMATURE ASM. | |
| 36. | VI5811291550 | [1] | BEARING, BALL | |
| 37. | VI1811291960 | [1] | BEARING, BALL | |
| 38. | VI5811150290 | [1] | BRACKET ASM, RR. | |
| 39. | VI5811160300 | [1] | BRUSH | KOBASM, (-) |
| 40. | VI5811180180 | [1] | HOLDER ASM, BRUSH | |
| 41. | VI5811150300 | [1] | BRACKET, RR. | |
| 42. | VI5811170140 | [4] | SPRING, BRUSH | |
| 43. | VI5811160290 | [2] | BRUSH ASM, {+) | |
| 44. | VI5811291640 | [2] | BOLT | |
| 53. | VI5811291690 | [1] | SEAL ASM. | |
