斗山零件查询REAR DOOR 440 PLUS Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
891 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
K1020669A
|
[-] |
REAR DOOR ASS'Y
|
|
| 1. |
K1020982
|
[1] |
DOOR;PLATE
|
|
| 10. |
S180130H
|
[1] |
PIN;SNAP
|
|
| 11. |
S0508863
|
[3] |
BOLT;M8X20
|
|
| 12. |
K1023154
|
[3] |
WASHER;HARDENED
|
|
| 13. |
K1019739
|
[2] |
RUBBER
|
|
| 14. |
K1019740
|
[4] |
RIVET
|
|
| 15. |
S0528063
|
[2] |
BOLT
|
|
| 16. |
K1022260
|
[4] |
SPACER
|
|
| 17. |
K1022261
|
[2] |
BEARING;SPHERICAL
|
|
| 18. |
K1019754
|
[2] |
SPACER;DOOR HINGE
|
|
| 19. |
S0558263
|
[1] |
BOLT
|
|
| 2. |
K1020650
|
[1] |
LEVER
|
|
| 20. |
S5010813
|
[2] |
WASHER;PLAIN
|
|
| 21. |
S4016633
|
[2] |
NUT
|
|
| 22. |
K1020684
|
[1] |
SPONGE
|
|
| 23. |
K1023030
|
[1] |
KNOB
|
|
| 24. |
S0505263
|
[1] |
BOLT
|
|
| 25. |
S4016333
|
[4] |
NUT
|
|
| 26. |
S5010313
|
[2] |
WASHER
|
|
| 27. |
K1020763
|
[2] |
SPONGE
|
|
| 28. |
S4017143
|
[2] |
NUT
|
|
| 29. |
K1021102
|
[3] |
SPONGE
|
|
| 3. |
K1020983
|
[1] |
ROD
|
|
| 30. |
K1028104
|
[1] |
SPONGE
|
|
| 31. |
K1028105
|
[1] |
SPONGE
|
|
| 4. |
K1019078
|
[1] |
PLATE;LATCH
|
|
| 5. |
K1020980
|
[1] |
PLATE;CABLE MOUNTING
|
|
| 6. |
K1019072
|
[1] |
SPRING
|
|
| 7. |
S5760061
|
[2] |
PIN
|
|
| 8. |
K1023037
|
[2] |
CLEVIS
|
|
| 9. |
S5000213
|
[2] |
. WASHER
|
|
