| 1. |
ZA104493
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, tractor half 540 RPM (Hayes Dana) (See Page 41) (Interchangeable with 96347C1) (P.I.N. 000501 thru 000800)
|
| 1. |
96347C1
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, tractor half 540 RPM (Weasler) (See Page 43) (Interchangeable with ZA104493) (P.I.N. 000801 thru 001280)
|
| 1. |
ZA104492
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, tractor half 1000 RPM (Hayes Dana) (See Page 41) (Interchangeable with 96346C1) (P.I.N. 000501 thru 000800)
|
| 1. |
96346C1
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, tractor half 1000 RPM (Weasler) (See Page 43) (Interchangeable with ZA104492) (P.I.N. 000801 thru 001280)
|
| 2. |
ZA104496
|
[1] |
JOINT
|
IH
ASSEMBLY - universal, implement half (Hayes Dana) (See Page 41) (Interchangeable with ZA017173) (P.I.N. 000501 thru 000800)
|
| 2. |
1336830C1
|
[1] |
JOINT
|
CAS
ASSEMBLY - universal, implement half (Weasler) (See Page 43) (Interchangeable with ZA104469) (P.I.N. 000801 thru 001280)
|
| 3. |
ZA105183
|
[1] |
SHAFT
|
IH
- drive
|
| 4. |
180177
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
- hex, 1/2 NC x 1-1/2 inch Superseded by part number: 113-410
|
| 5. |
9413956
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138
|
| 6. |
ZA104323
|
[1] |
BRACKET
|
IH
- power take off drive
|
| 7. |
ZA103821
|
[1] |
BUMPER
|
IH
- rubber
|
| 8. |
97480C1
|
[1] |
HOUSING, BEARING
|
IH
HOUSING - bearing
|
| 9. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PT 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 10. |
478038R92
|
[1] |
BALL BEARING,38.1mm ID x 80mm OD x 21mm W
|
IH
|
| 11. |
455112R11
|
[1] |
COLLAR
|
IH
- with set screw Superseded by part number: 47577185
|
| 12. |
125843
|
[1] |
SET SCREW,Hex Skt, 3/8"-16 x 3/8"
|
IH
SCREW - set, hex socket headless cup point, 3/8 NF x 3/8 inch Superseded by part number: 86624120
|
| 13. |
ZA740950
|
[1] |
DECAL
|
CAS
- warning, shield Superseded by part number: ZA211862
|
| 15. |
ZA516382
|
[1] |
YOKE
|
IH
|
| 16. |
Q55
|
[1] |
KEY,3/8" Sq x 2", Par
|
IH
- square parallel, 3/8 x 2 inch
|
| 17. |
553110R1
|
[1] |
LOCK PIN,5/16" x 2 3/4", Slotted
|
CAS
Pin, 5/16" x 2 3/4", Slotted Superseded by part number: 38-12044
|
| 18. |
80711
|
[1] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING - grease, 65 degree, 1/8-27 inch PT
|
| 19. |
660116R91
|
[1] |
NUT
|
IH
KIT - cross Superseded by part number: 84355326
|
| 20. |
664179R1
|
[1] |
YOKE
|
IH
|
| 21. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 22. |
38904K
|
[1] |
SET SCREW,1/2" - 20 x 1-9/16"
|
IH
SCREW - square head, 1/2 NC x 1-3/16 inch
|
| 23. |
REF
|
[1] |
INSTRUCTION
|
NH
GEAR BOX (See Page 39)
|
| 24. |
ZA105085
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET - 16 teeth
|
| 25. |
1254030C1
|
[1] |
RING
|
IH
- retaining
|
| 26. |
22051R1
|
[1] |
WASHER
|
IH
- flat, 1-17/32 x 2-1/4 x 3/64 inch (38 x 57 x 1 mm) Superseded by part number: Q302
|
| 27. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
CHAIN ASSEMBLY - (Use 15 links from roll 28363R1 and 1 connecting link 38361R1)
|
| . . |
28362R1
|
[1] |
CHAIN - 10 foot (3.048 m) roll
|
|
| . . |
28361R1
|
[1] |
LINK
|
IH
- connecting Superseded by part number: 241-1326
|
| 28. |
ZA105187
|
[1] |
SHIELD
|
IH
ASSEMBLY
|
| 29. |
96330C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - caution, general safety
|
| 30. |
96332C1
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - caution, shields (Replaces ZA015966)
|
