神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-033) - GENERATOR (NIKKO) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
422 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5812003440 | [1] | GENERATOR ASM, 24V-25A | |
| 2. | VI1196000140 | [1] | VACUM PUMP ASM. | |
| 3. | VI1812240090 | [1] | SLIP RING | |
| 4. | VI1812292250 | [1] | BEARING | KOBBALL |
| 5. | VI1812292240 | [1] | BALL BEARING | KOBBEARING BALL Superseded by part number: 1812292240 |
| 6. | VI1812291610 | [1] | RETAINER | |
| 7. | VI1812291630 | [1] | RETAINER | |
| 8. | VI1812291640 | [1] | RETAINER | |
| 9. | VI9822160600 | [1] | RETAINER | |
| 10. | VI1812291230 | [1] | PLATE | |
| 11. | VI1812291600 | [1] | COLLAR | |
| 12. | VI1811180200 | [1] | CLIP | |
| 13. | VI1812292300 | [1] | CLIP | |
| 14. | VI1812510240 | [1] | CONTROL UNIT | KOBREGULATOR ASM. Superseded by part number: 1812510240 |
| 15. | VI1812292160 | [1] | CLIP | |
| 16. | VI1812291670 | [1] | BUSH, GUM | |
| 17. | VI1812291350 | [1] | WASHER, INSULATE | |
| 18. | VI1812292270 | [1] | WASHER, INSULATE | |
| 19. | VI1812292350 | [1] | BUSH, INSULATE | |
| 20. | VI1812292340 | [1] | TUBE, INSULATE | |
| 21. | VI1812170230 | [1] | BRUSH HOLDER | KOBHOLDER ASM, BRUSH Superseded by part number: 1812170330 |
| 22. | VI1812290330 | [1] | RECTIFIRE ASM. | |
| 24. | VI1812293100 | [1] | BOLT | |
| 25. | VI1812290970 | [3] | BOLT | |
| 26. | VI1812291650 | [1] | PACKING | |
| 27. | VI1812291620 | [1] | PACKING | |
| 28. | VI1812292310 | [1] | PACKING | |
| 30. | VI1812292260 | [1] | PACKING | |
| 31. | VI1812292320 | [1] | PACKING | |
| 32. | VI1812292410 | [1] | PACKING | |
| 33. | VI1812292420 | [1] | PACKING | |
| 34. | VI1812110310 | [1] | STATOR ASM. | |
| 35. | VI5812130470 | [1] | BRACKET ASM, FRONT | |
| 36. | VI5812220740 | [1] | PULLEY | |
| 37. | VI5812141430 | [1] | BRACKET ASM, REAR | |
| 38. | VI5812141440 | [1] | BRACKET, REAR | |
| 39. | VI1812210330 | [1] | ROTOR ASM. | |
| 41. | VI1812291560 | [1] | VALVE ASM. | |
| 42. | VI1812291550 | [4] | VANE | |
| 43. | VI5196190260 | [1] | BOLT | |
| 44. | VI5196190290 | [1] | BOLT | |
| 45. | VI5196190280 | [1] | BOLT | |
| 46. | VI5196190270 | [3] | BOLT | |
| 47. | VI1812292390 | [1] | SEAL, OIL | |
| 48. | VI1812292690 | [2] | O-RING | |
| 49. | VI1812292710 | [5] | WASHER | |
| 50. | VI1812292700 | [2] | WASHER | |
| 51. | VI1812291590 | [1] | SEAL ASM. | |
