神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-035) - GENERATOR (NIKKO) (P/N-581200-2121) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
803 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5812002121 | [1] | ALTERNATOR | KOBGENERATOR ASM, 24V-15A |
| I. | VI5812210570 | [1] | ROTOR | KOBROTER ASM |
| 2. | VI5812291680 | [1] | BEARING BALL | |
| 3. | VI9822158390 | [1] | RETAINER | |
| 4. | VI5812240020 | [1] | SLIP RING | |
| 5. | VI5811290970 | [1] | COLLER | |
| 6. | VI5812290980 | [1] | RETAINER | |
| 7. | VI5812291670 | [1] | BALL BEARING | KOBBEARING BALL Superseded by part number: VI5812291410 |
| 8. | VI5095030640 | [1] | WASHER | |
| 9. | VI5812510150 | [1] | REGULATOR | KOBASM |
| 10. | VI5812141080 | [1] | BRACKET ASH, RR. | |
| 11. | VI5812150410 | [1] | BRUSH HOLDER | KOBHOLDER ASM, BRUSH |
| 12. | VI5812291700 | [2] | FOAM INSULATION | KOBBUSH, INSULATE Superseded by part number: 1812290420 |
| 13. | VI5812291710 | [1] | TUBE, INSULATE | |
| 14. | VI5812291720 | [1] | TUBE, INSULATE | |
| 15. | VI5812141130 | [1] | U-BRACKET | KOBBRACKET, RR. |
| 16. | VI5812180320 | [1] | RECTIFIER ASM. | |
| 17. | VI1812292370 | [2] | BUSH, INSULATE | |
| 18. | VI5090002380 | [1] | BOLT, B.TERMINAL | |
| 19. | VI5090002390 | [1] | BOLT, R.TERMINAL | |
| 20. | VI5812110330 | [1] | STATOR | KOBSTATOR ASM. |
| 21. | VI5812130450 | [1] | BRACKET, FRT | |
| 22. | VI5090002400 | [3] | BOLT | |
| 23. | VI5812220670 | [1] | PULLEY | KOBASM. |
