神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-036) - GENERATOR (NIKKO) (P/N-894404-7910) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
841 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8944047910 | [1] | GENERATOR ASM. | |
| 1. | VI8941730540 | [1] | BALL BEARING | KOBBEARING BALL |
| 2. | VI8941730600 | [1] | RETAINER | |
| 3. | VI8944164430 | [1] | ROTOR ASM. | |
| 4. | VI8941730550 | [1] | COLLAR | |
| 5. | VI8941730580 | [1] | RETAINER | |
| 6. | VI1812292790 | [1] | BALL BEARING | KOBBEARING Superseded by part number: 1812292790 |
| 7. | VI8941730590 | [1] | RETAINER | |
| 8. | VI8941730560 | [1] | COLLAR | |
| 9. | VI1812295280 | [1] | TIRMINAL ASM. | |
| 10. | VI1812291220 | [1] | CLIP | |
| 11. | VI8944164450 | [1] | BRACKET ASM, REAR | |
| 12. | VI8941730610 | [1] | BUSH, INSULATE | |
| 13. | VI8941730720 | [1] | BOLT | |
| 14. | VI8944164470 | [1] | REGULATOR ASM. | |
| 15. | VI8944164480 | [1] | BRACKET, REAR | |
| 16. | VI8944164490 | [1] | RECTIFIRE ASM. | |
| 17. | VI8944164500 | [1] | BOLT | |
| 18. | VI8944164510 | [1] | STATOR, ASM. | |
| 19. | VI8944164520 | [1] | BRACKET ASM, FRONT | |
| 20. | VI8941730710 | [3] | SCREW | |
| 21. | VI8941730700 | [1] | FAN | KOBFAN Superseded by part number: 8941730700 |
| 22. | VI8944164530 | [1] | PULLEY | |
| 23. | VI1812294790 | [1] | WASHER | KOBWASHER, SPR |
| 24. | VI8941730800 | [1] | NUT | |
| 25. | NSS | [2] | NOT SOLD SEPARAT | CONBRUSH ASM. |
