凯斯零件查询(3450) - CASE IH ROUND TIE BALER (1/83-12/89) (48) - BELTS & ROLLER ASSYS 1 - 6, MACHINES W/ 1.378" (35 MM) ID BEARINGS, PRIOR TO P.I.N. 001280, CONT'D Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
813 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 30. |
ZA104227
|
[2] |
SPROCKET ASSY.
|
IH
SPROCKET - 30 teeth
|
| . . |
180130
|
[8] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
IH
- hex, 3/8 NC x 2 inch Superseded by part number: 113-219
|
| 31. |
ZA104593
|
[2] |
HUB
|
IH
|
| 32. |
351107R1
|
[2] |
WASHER
|
IH
- flat
|
| 33. |
27908R1
|
[2] |
BOLT,1/2" x 1 1/4", Gr 8
|
CAS
- hex, 1/2 NC x 1-1/4 inch type 8
|
| 34. |
ZA104649
|
[1] |
ARM
|
IH
|
| 35. |
96315C1
|
[1] |
BRONZE BUSHING
|
IH
BUSHING
|
| 36. |
1281008C1
|
[1] |
SPRING
|
IH
|
| 37. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
CHAIN ASSEMBLY - (Use 151 links from roll marked 611362R91 and 1 connecting link 574532R91)
|
| . . |
611362R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - 10 foot (3.048 m) roll Superseded by part number: 611362R91X
|
| . . |
574532R91
|
[1] |
CLIP, SPRING
|
IH
LINK - connecting Superseded by part number: 241-1316
|
| 38. |
67872C1
|
[1] |
WASHER
|
IH
- flat, 21/32 x 1-1/4 x 1/4 inch (16 x 31 x 6 mm)
|
| 39. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
IDLER ASSEMBLY - 15 teeth
|
| 40. |
271723
|
[1] |
SNAP RING,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
- hex, 5/8 NC x 2 inch Superseded by part number: 413-1032, 413-1032, NLS
|
| 41. |
445608
|
[2] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5
|
IH
- hex, 1/2 NC x 5-1/2 inch Superseded by part number: 88576
|
| 42. |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 43. |
ZA761370
|
[2] |
SPRING
|
IH
|
| 44. |
1281009C1
|
[2] |
INSERT
|
IH
|
| 45. |
120396
|
[1] |
WASHER
|
IH
- flat, 17/32 x 1-1/16 x 3/32 inch (13 x 26 x 2 mm) Superseded by part number: 495-11053, 495-11053, NLS
|
| . . |
208790C1
|
[1] |
PACKAGE
|
IH
KIT - belt repair (Box of lacing hooks)
|
| . . |
1254050C1
|
[1] |
TOOL
|
IH
LACER - belt (6 inch) Superseded by part number: 828459
|
