| 1. |
ZA104905
|
[1] |
SHAFT
|
IH
ASSEMBLY - pivot left
|
| 2. |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 3. |
667486R1
|
[2] |
BOLT
|
IH
BOLT - special hex, 1/2 NC x 3-1/2 inch
|
| 4. |
1336821C1
|
[8] |
SCREW,Lock, Flat Csk Hd, 3/8" - 16 x 125mm
|
CAS
- flat head countersunk, 3/8 NC x 1 inch
|
| 5. |
ZA104877
|
[1] |
PIVOT
|
IH
- idler
|
| . . |
180183
|
[4] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5
|
IH
- hex, 1/2 NC x 2-1/4 inch Superseded by part number: 113-441
|
| 6. |
9413956
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138
|
| 7. |
ZA105799
|
[6] |
COLLAR
|
CAS
- bearing
|
| 8. |
ZA104906
|
[1] |
SHAFT
|
IH
ASSEMBLY - pivot right
|
| 9. |
ZA105794
|
[10] |
BALL BEARING
|
CAS
BEARING - hex bore, 1-1/4 inch ID (31 mm) Superseded by part number: 47442495
|
| 10. |
ZA105777
|
[1] |
ROLLER
|
CAS
- spring loaded (No. 1) (Note A)
|
| 11. |
ZA104878
|
[1] |
DIVIDER
|
IH
|
| 12. |
ZA105775
|
[2] |
ROLLER
|
CAS
(No. 2 and 3) (Note B) Superseded by part number: 228681A1, 228695A1
|
| 13. |
ZA105796
|
[4] |
COLLAR
|
CAS
- bearing
|
| 14. |
ZA104975
|
[2] |
STRIPPER
|
IH
Superseded by part number: ZA106780
|
| 15. |
ZA105782
|
[2] |
ROLLER
|
CAS
- drive (No. 4 and 6) (Note C) Superseded by part number: 228687A1, 228695A1
|
| 16. |
ZA104982
|
[2] |
CLIP
|
IH
- angle
|
| 17. |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 18. |
ZA104987
|
[1] |
BRACKET
|
IH
TIGHTENER - left
|
| . . |
180124
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
|
| . . |
189305
|
[1] |
BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 5
|
IH
- hex, 3/8 NC x 3-1/2 inch Superseded by part number: 186283
|
| 19. |
ZA105776
|
[1] |
ROLLER
|
CAS
- idler (No. 5) (Note A) Superseded by part number: 228695A1, 228682A1
|
| 20. |
ZA105548
|
[1] |
DIVIDER
|
IH
|
| . . |
17351R1
|
[4] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 88682
|
| . . |
20803R1
|
[4] |
WASHER
|
IH
- flat, 17/32 x 1 x 1/8 inch (10 x 24 x 3 mm) Superseded by part number: 87613212
|
| 21. |
ZA104765
|
[5] |
BELT
|
IH
- bottom endless (11 inch wide) Superseded by part number: 225969A1
|
| 22. |
ZA104712
|
[5] |
BELT
|
IH
- Bottom (11 inch wide) Superseded by part number: 700711081, 700724729
|
| 23. |
ZA102977
|
[5] |
PIN
|
IH
|
| 24. |
ZA105005
|
[5] |
BELT
|
IH
- top endless (11 inch wide) Superseded by part number: 700709544
|
| 25. |
ZA105003
|
[5] |
BELT
|
IH
- Top (11 inch wide) Superseded by part number: 700724731
|
| 27. |
ZA104986
|
[1] |
BRACKET
|
IH
TIGHTENER - right
|
| 28. |
ZA104841
|
[2] |
HOUSING
|
IH
- bearing
|
| 29. |
96328C1
|
[2] |
BALL BEARING,40mm ID x 80mm OD x 22mm W
|
CAS
- 1.5753 ID (40 mm)
|
