神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-038) - GENERATOR (HITACHI) (P/N-581200-1011) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
367 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5812001011 | [1] | GENERATOR ASM, 24V-15A | |
| 5. | VI5812210220 | [1] | ROTOR ASM. | |
| 8. | VI9000901810 | [1] | BEARING HALF | KOBBEARING BALL, FRT. Superseded by part number: VI8943335210 |
| 20. | VI5812110640 | [1] | STARTER ASM. | |
| 25. | VI5812140250 | [1] | COVER ASM, RR. | |
| 27. | VI5812180210 | [1] | RECTIFIRE ASM. | |
| 30. | VI5812170090 | [1] | HOLDER ASM, BRUSH | |
| 33. | VI5812180100 | [1] | COVER, RECTIFIRE | |
| 35. | VI9822350700 | [1] | BOLT ASM, TERMINAL | |
| 50. | VI5812130140 | [1] | COVER ASM, FRT | |
| 52. | VI9822158230 | [1] | PACKING | |
| 53. | VI9822158240 | [1] | RETAINER | |
| 54. | VI9822159170 | [1] | RETAINER, BRG. | |
| 55. | VI9000901820 | [1] | BEARING, FRT. | |
| 75. | VI5812220270 | [1] | PULLEY ASM. | |
| 80. | VI9822350740 | [1] | NUT ASM., PULLEY | |
| 90. | VI9822350720 | [2] | BOLT, THROUGH | |
| 90-1. | VI9822350730 | [1] | BOLT, THROUGH | |
| 93. | VI9822250290 | [1] | KEY, PULLEY | |
