神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-037) - GENERATOR (HITACHI) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
704 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5812003470 | [1] | GENERATOR ASM, 12V-50A | |
| 8. | VI5812210710 | [1] | ROTOR ASM. | |
| 9. | VI9000901810 | [1] | BEARING HALF | KOBBEARING BALL Superseded by part number: VI8943335210 |
| 11. | VI5812110670 | [1] | STATOR ASM. | |
| 14. | VI5812141520 | [1] | COVER ASM, REAR | |
| 15. | VI5812141530 | [1] | COVER, REAR | |
| 16. | VI5812190390 | [1] | REGURATOR ASM, BRUSH | |
| 17. | VI581215 0470 | [1] | BRUSH ASM. | |
| 18. | VI5812291970 | [1] | PACKING | |
| 19. | VI5812291660 | [2] | BOLT | |
| 20. | VI5812150400 | [2] | MOTOR HOUSING | KOBBRUSH SET |
| 21. | VI5812700040 | [1] | REGURATOR ASM, I.C | |
| 22. | VI5812620060 | [1] | DIODE ASM. | |
| 26. | VI5812130560 | [1] | COVER ASM, FRONT | |
| 28. | VI8942336490 | [1] | RETAINER, BRG. | |
| 29. | VI8942336530 | [1] | SCREW KIT | |
| 30. | VI8942336520 | [1] | NUT ASM, PULLEY | |
| 32. | VI8942127140 | [1] | BEARING, BALL | |
| 34. | VI8942336510 | [4] | BOLT, THROUGH | |
| 40. | VI5812220860 | [1] | PULLEY ASM. | |
