| 1. |
668902R1
|
[1] |
BELT
|
IH
- Speed up (Used with sheave ZA104645) (Interchangeable with ZA104774)
|
| 1. |
ZA104774
|
[1] |
BELT
|
IH
- Slow speed (Used with sheave ZA104842) (Interchangeable with 668902R1)
|
| 2. |
27908R1
|
[3] |
BOLT,1/2" x 1 1/4", Gr 8
|
CAS
- hex, 1/2 NC x 1-1/4 inch type 8
|
| 3. |
351107R1
|
[3] |
WASHER
|
IH
- flat, 17/32 x 2 x 1/4 inch (13 x 50 x 6 mm)
|
| 4. |
ZA104645
|
[1] |
PULLEY
|
IH
SHEAVE - speed up (Used with belt 668902R1) (Interchangeable with ZA104842)
|
| 4. |
ZA104842
|
[1] |
PULLEY
|
IH
SHEAVE - slow down (Used with belt ZA104774) (Interchangeable with ZA104645)
|
| 5. |
22051R1
|
[1] |
WASHER
|
IH
- flat, 1-17/32 x 2-1/4 x 1/16 inch (30 x 57 x 1 mm) Superseded by part number: Q302
|
| 6. |
663562R1
|
[1] |
FLANGE
|
IH
HOUSING - bearing
|
| 7. |
96328C1
|
[3] |
BALL BEARING,40mm ID x 80mm OD x 22mm W
|
CAS
- 1.5753 inch ID (40 mm)
|
| 8. |
ZA104824
|
[1] |
PLATE
|
IH
- left
|
| . . |
180077
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
- hex, 5/16 NC x 3/4 inch Superseded by part number: 87872
|
| 9. |
ZA104736
|
[1] |
ROLLER
|
IH
- pivot (No. 10)
|
| 10. |
ZA104823
|
[1] |
PLATE
|
IH
- right
|
| 11. |
ZA104939
|
[1] |
STRIPPER
|
IH
|
| 12. |
432-1216
|
[1] |
COTTER PIN,3/16" x 1"
|
CAS
Pin, Split (Cotter), 3/16" x 1"
|
| 13. |
27342R1
|
[1] |
WASHER
|
IH
WASHER - flat, 17/32 x 1 x 1/16 inch (13 x 25 x 1 mm) Superseded by part number: 495-81254
|
| 14. |
ZA104215
|
[1] |
ARM
|
IH
|
| . . |
180183
|
[1] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5
|
IH
- hex, 1/2 NC x 2-1/4 inch Superseded by part number: 113-441
|
| 15. |
21993R1
|
[1] |
SPLIT PIN/SAFETY PIN
|
IH
PIN - headed, 1/2 x 3-1/2 inch Superseded by part number: 86624062
|
| 16. |
ZA103001
|
[1] |
PULLEY
|
IH
IDLER - belt
|
| 17. |
ZA271276
|
[1] |
SPRING
|
IH
|
| 18. |
ZA201085
|
[1] |
INSERT
|
IH
- lift spring
|
| 19. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 20. |
445608
|
[1] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5
|
IH
- hex, 1/2 NC x 5-1/2 inch Superseded by part number: 88576
|
| 21. |
ZA105548
|
[2] |
DIVIDER
|
IH
- (For 11 inch wide belts)
|
| . . |
17351R1
|
[8] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 88682
|
| . . |
21403R1
|
[4] |
WASHER
|
IH
- flat, 13/32 x 1 x 1/8 inch (10 x 24 x 3 mm) Superseded by part number: 87613212
|
| 22. |
ZA104982
|
[4] |
CLIP
|
IH
- angle
|
| 23. |
120377
|
[8] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 24. |
ZA104987
|
[2] |
BRACKET
|
IH
TIGHTENER - left
|
| . . |
180124
|
[6] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
|
| . . |
189305
|
[2] |
BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 5
|
IH
- hex, 3/8 NC x 3-1/2 inch Superseded by part number: 186283
|
| 25. |
ZA105799
|
[5] |
COLLAR
|
CAS
- bearing
|
| 26. |
ZA105794
|
[5] |
BALL BEARING
|
CAS
BEARING - hex bore, 1-1/4 inch ID (31 mm) Superseded by part number: 47442495
|
| 27. |
ZA105776
|
[2] |
ROLLER
|
CAS
- idler (No. 7 and 9) (Note A) Superseded by part number: 228695A1, 228682A1
|
| 28. |
ZA105782
|
[1] |
ROLLER
|
CAS
- drive (No. 8) (Note B) Superseded by part number: 228687A1, 228695A1
|
| 29. |
ZA104975
|
[1] |
STRIPPER
|
IH
Superseded by part number: ZA106780
|
| 30. |
ZA105003
|
[10] |
BELT
|
IH
- Top (11 inch wide) Superseded by part number: 700724731
|
| 31. |
ZA102977
|
[10] |
PIN
|
IH
(For 11 inch wide belt)
|
