神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-007) - FLYWHEEL HOUSING & OTHER PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
975 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5. | VI8943204413 | [1] | HOUSING,FLYWHEEL | |
| 5. | VI8944228787 | [1] | HOUSING,FLYWHEEL | |
| 5. | VI8943184074 | [1] | HOUSING,FLYWHEEL | |
| 5-1. | VI8944419473 | [1] | HOUSING,FLYWHEEL | |
| 5-4. | VI8943415310 | [1] | HOUSING,FLYWHEEL | |
| 5-2. | VI8943439271 | [1] | HOUSING,FLYWHEEL | |
| 5-3. | VI5113410050 | [1] | HOUSING,FLYWHEEL | |
| 6. | VI9992023120 | [1] | PLUG,SCREW | |
| 6. | VI9992023160 | [1] | PLUG | KOBPLUG,SCREW Superseded by part number: VI0920024160 |
| 7. | VI9095714120 | [1] | GASKET | |
| 7. | VI9095714160 | [1] | SEAL | KOBGASKET |
| 10. | VI5090002270 | [3] | BOLT | KOBBOLT,HOUSING FIX. L=25 |
| 10-1. | VI0500412300 | [2] | BOLT,HOUSING FIX. | |
| 10-1. | VI0500410300 | [3] | BOLT,HOUSING FIX. | |
| 14. | VI9098300770 | [2] | STUD,FLYWHEEL HOUSING | |
| 15. | VI9091105100 | [2] | NUT | KOBNUT,HOUSING FIX. |
| 16. | VI9091505100 | [2] | WASHER | KOBWASHER,SPR. Superseded by part number: VI1099853450 |
