神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-008) - FLYWHEEL HOUSING & OTHER PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
664 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5. | VI8971762140 | [1] | HOUSING,FLYWHEEL | |
| 5. | VI8944228787 | [1] | HOUSING,FLYWHEEL | |
| 5. | VI8943204413 | [1] | HOUSING,FLYWHEEL | |
| 5. | VI8943184074 | [1] | HOUSING,FLYWHEEL | |
| 5-1. | VI8970698070 | [1] | HOUSING,FLYWHEEL | |
| 5-1. | VI8970789240 | [1] | HOUSING,FLYWHEEL | |
| 5-4. | VI8943415310 | [1] | HOUSING,FLYWHEEL | |
| 6. | VI9992023160 | [1] | PLUG | KOBPLUG,SCREW Superseded by part number: VI0920024160 |
| 7. | VI9095714160 | [1] | SEAL | KOBGASKET |
| 8. | VI1096050800 | [1] | PLUG,TACHO SENSOR | |
| 9. | VI9095714200 | [1] | GASKET,PLUG | |
| 10. | VI0500410300 | [1] | BOLT,SEMS,HSG TO BODY | |
| 10. | VI5090002270 | [3] | BOLT | KOBBOLT,HOUSING FIX.M12 L=25 |
| 10-1. | VI0500412300 | [2] | BOLT,HOUSING FIX. | |
| 10-1. | VI0500410300 | [3] | BOLT,HOUSING FIX. | |
| 14. | VI8941077260 | [2] | STUD | KOBSTUD,FLYWHEEL HOUSING |
| 16. | VI9091505100 | [2] | WASHER | KOBWASHER,SPRING Superseded by part number: VI1099853450 |
| 19. | VI9091105100 | [2] | NUT | KOBNUT,HOUSING |
