凯斯零件查询(3450) - CASE IH ROUND TIE BALER (1/83-12/89) (82) - SAFETY CHAIN Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
206 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
100682C3
|
[1] |
CHAIN (AG)
|
IH
CHAIN - safety
|
| 2. |
148558C1
|
[1] |
CLEVIS
|
IH
- safety chain (Replaces S9173A) Superseded by part number: 1279163C1
|
| . . |
61913C92
|
[1] |
PACKAGE
|
IH
KIT - safety chain hardware Superseded by part number: 495-81047, 413-1056, 413-1244, 231-14412, 231-14110, 148558C1
|
| 3. |
271729
|
[1] |
BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5
|
IH
- hex, 5/8 NC x 3-1/2 inch Superseded by part number: 413-1056, 413-1056, NLS
|
| 4. |
19508R1
|
[1] |
LOCK NUT,5/8"-11, GB
|
IH
NUT - hex lock, 5/8 inch NC Superseded by part number: 86639566
|
| 5. |
80280173
|
[1] |
BOLT,Hex, 3/4" - 10 x 2 3/4", Gr 5
|
IMO
- hex, 3/4 x 2-3/4 inch
|
| 6. |
26512R1
|
[1] |
WASHER
|
IH
- flat, 25/32 x 2 x 11/64 inch (19 x 50 x 4 mm) Superseded by part number: 86624159
|
| 7. |
18444R1
|
[1] |
NUT,3/4"-10, GB
|
IH
- hex lock, 3/4 inch NC Superseded by part number: 22244R1
|
