凯斯零件查询(3450) - CASE IH ROUND TIE BALER (1/83-12/89) (80) - BALE COUNTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
870 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
ZA105788
|
[1] |
PACKAGE
|
IH
KIT - bale counter
|
| 1. |
ZA103965
|
[1] |
COUNTER
|
IH
BALE
|
| 2. |
656707R91
|
[1] |
ARM
|
IH
LEVER ASSEMBLY
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
SCREW - slotted head, No. 5-44 x 5/16 inch (Order lever, 656707R91)
|
| 4. |
495525R1
|
[1] |
SPRING
|
IH
- bale counter
|
| 5. |
159203
|
[4] |
SCREW,Cross Pan Hd, #4 - 40 x 1/2"
|
IH
- pan head cross recess, No. 4 x 1/2 inch Superseded by part number: 440-1048
|
