神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-017[01]) - OIL FILTER, FUEL FILTER & FIXING PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
151 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8944621371 | [1] | FILTER ASM,OIL | |
| 1. | VI8970215530 | [1] | FILTER ASM,OIL | |
| 1. | VI8943163420 | [1] | FILTER ASM,,OIL | |
| 1-2. | VI8941754691 | [1] | FILTER & COOLER, OIL | |
| 2. | VI8944289310 | [1] | ELEMENT | KOBCARTRIDGE KIT,O/F. D=102 Superseded by part number: 2451U303-1 |
| 2. | VI8943604260 | [1] | ELEMENT | KOBCARTRIDGE KIT,OIL FILTER Superseded by part number: 84160287 |
| 2. | VI8970497080 | [1] | CARTRIDGE KIT,O/F. D=90 | |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONBODY ASH. |
| 3. | VI8943296220 | [1] | BODY ASM. | |
| 3-3. | VI8944016781 | [1] | BODY ASH. | |
| 4. | VI8941678820 | [1] | VALVE ASH. | |
| 5. | VI8941678830 | [1] | PLUG | |
| 8. | VI8941678840 | [1] | O-RING | KOBO-RING |
| 9. | VI8941678850 | [1] | O-RING | KOBO-RING |
| 10. | VI8941678860 | [1] | GASKET | KOBO-RING |
| 11. | VI9000970110 | [1] | BALL,STEEL | |
| 12. | VI8944016790 | [1] | SPRING,BALL | |
| 13. | VI8944016800 | [1] | COOLER ASH,OIL | |
| 14. | VI8943432160 | [1] | NUT | |
| 15. | VI8943837200 | [1] | GASKET | |
| 18. | VI8970659830 | [1] | GASKET | KOBPACKING,OIL FILTER Superseded by part number: VI8980879650 |
| 21. | VI0501408300 | [1] | SPECIAL BOLT | KOBBOLT,OIL FILTER FIX. Superseded by part number: VI0506408300 |
| 30. | VI8941434771 | [1] | FILTER ASSY | KOBFILTER ASH,FUEL Superseded by part number: VI8971798541 |
| 30. | VI8941517451 | [1] | FILTER | KOBFILTER ASH,FUEL(95-4-) Superseded by part number: VI8971798541 |
| 30. | VI8970116850 | [1] | FILTER ASH,FUEL | |
| 30-1. | VI8943691483 | [1] | FILTER ASH,FUEL | |
| 30-1. | VI8970286962 | [1] | FILTER ASH,FUEL | |
| 31. | VI8941517440 | [1] | CARTRIDGE | KOBCARTRIDGE,FUEL FILTER Superseded by part number: VI8944147963 |
| 31. | VI8941434790 | [1] | ELEMENT | KOBCARTRIDGE,FUEL FILTER Superseded by part number: EN02P00001-2 |
| 31-1. | VI8943329551 | [1] | CARTRIDGE KIT,FUEL FILTER | |
| 31-1. | VI8943692991 | [1] | ELEMENT | KOBCARTRIDGE KIT ."FUEL FILTER Superseded by part number: PY02P00001-2 |
| 32. | VI5132120751 | [1] | COVER | KOBCOVER,FUEL FILTER Superseded by part number: 76615430 |
| 33. | VI9132600562 | [1] | VALVE | KOBVALVE ASH,OVER FLOW |
| 33. | VI8970116860 | [1] | VALVE ASH,OVER FLOW | |
| 34. | VI9095720140 | [2] | PACKING | KOBPACKING,JOINT BOLT |
| 36. | VI9092023080 | [1] | SCREW | KOBPLUG,OVER FLOW VALVE |
| 37. | VI9095714080 | [1] | PACKING | KOBPACKING,PLUG Superseded by part number: 289808A1 |
| 38. | VI8944104040 | [1] | BRACKET | KOBBRACKET,FUEL FILTER |
| 39. | VI9096300200 | [2] | PIPE | KOBSTUD,BRKT. L1=24 Superseded by part number: VI8943427130 |
| 40. | VI0500410320 | [2] | BOLT | KOBOIL FILTER FIX. Superseded by part number: VI0505410400 |
| 41. | VI9091105100 | [2] | NUT | KOBNUT,BRKT.FIX |
| 42. | VI9091505100 | [2] | WASHER | KOBWASHER,SPR. Superseded by part number: VI1099853450 |
| 62. | VI8944501333 | [1] | BODY ASM | |
| 62-1. | VI8970286973 | [1] | BODY ASM. | |
| 63. | VI8941326740 | [1] | PLUG | |
| 64. | VI8941326750 | [1] | GASKET | |
| 66. | VI8944501390 | [1] | SENSOR ASM | |
| 66. | VI8970287000 | [1] | SENSOR ASM. | |
| 67. | VI8944501420 | [1] | SENSOR | |
| 67. | VI8970286980 | [1] | SENSOR | |
| 68. | VI8944501460 | [1] | PLUG ASM. | |
| 68. | VI8970286990 | [1] | PLUG ASM. | |
| 70. | VI8970209410 | [1] | SEDIMENTER ASM,WATER | |
| 70. | VI1132008410 | [1] | OIL SEPARATOR | KOBSEDIMENTER ASM,WATER Superseded by part number: VI8972186470 |
| 72. | VI5096230700 | [1] | O-RING | KOBO-RING |
| 73. | VI5132120591 | [1] | COVER | KOBBODY |
| 74. | VI5096300240 | [1] | GASKET | KOBGASKET |
| 75. | VI5132190200 | [1] | BOLT | KOBPLUG |
| 76. | VI5132110231 | [1] | CASE ASM. | |
| 76. | VI1132112110 | [1] | BODY | KOBCASE ASM. |
| 77. | VI5132190210 | [1] | FLOAT | KOBFLOAT |
| 78. | VI5096800140 | [1] | PLUG | |
| 78-1. | VI8944537460 | [1] | PLUG | KOBPLUG ASM. |
| 79. | VI5096230690 | [1] | O-RING | |
| 79-1. | VI8944163770 | [1] | GASKET | KOBO-RING Superseded by part number: VI8941678860, 77272159 |
| 80. | VI5136190221 | [1] | RING | KOBRING, RETAINER Superseded by part number: VI5132190221 |
