| 1. |
ZA105685
|
[1] |
FITTING
|
IH
ORIFICE ASSEMBLY - 9/16-18 x 3/4-16 inch, 0.052 inch (1.321 mm) dia.
|
| 2. |
570828R1
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
IH
- 41/64 x 13/16 x 3/32 inch (16 x 21 x 2 mm) Superseded by part number: 128825
|
| 3. |
REF
|
[1] |
INSTRUCTION
|
NH
CONNECTOR - 3/8 inch tube (See Page 27)
|
| 5. |
129768C1
|
[2] |
HYDRAULIC HOSE
|
IH
HOSE ASSEMBLY - 1/4 ID x 115 inch (6 x 2 921 mm)
|
| 6. |
1264172C2
|
[4] |
HYDRAULIC HOSE,6.40 mm ID x 2665.00 mm, SAE 100R1
|
IH
HOSE ASSEMBLY - 1/4 ID x 105 inch (6 x 2 667 mm)
|
| 7. |
76355
|
[2] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
- 3/8 inch tube
|
| 8. |
27291R1
|
[16] |
CLAMP
|
IH
- tube Superseded by part number: 9827902
|
| 9. |
9635884
|
[8] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
- hex, 5/16 NC x 1 inch
|
| 10. |
120393
|
[8] |
BEARING WASHER,5/16", SAE
|
IH
WASHER - flat, 11/32 x 11/16 x 3/64 inch (9 x 17 x 1 mm) Superseded by part number: 28588R1
|
| 11. |
80681
|
[8] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 12. |
120376
|
[8] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 14. |
ZA105118
|
[4] |
GUIDE
|
IH
- hose
|
| 15. |
333934R1
|
[4] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/8"-18, NPTF
|
IH
- 3/8 tube x 3/8 inch PT, 90 degree Superseded by part number: 235131
|
| 16. |
ZA103758
|
[2] |
VALVE
|
IH
- rotary
|
| 17. |
443981
|
[2] |
CONNECTOR, ELEC
|
IH
NIPPLE - pipe, 3/8 inch PT Superseded by part number: 217-1081
|
| 22. |
63196C1
|
[4] |
PIN
|
IH
- clevis Superseded by part number: 427-16400
|
| 23. |
32-1632
|
[8] |
COTTER PIN,1/4" x 2"
|
CAS
PIN, SPLIT (COTTER), 1/4" x 2" Superseded by part number: 88182
|
| 24. |
591715R1
|
[8] |
WASHER
|
IH
- flat, 1-1/32 x 1-1/2 x 1/16 inch (26 x 38 x 2 mm) Superseded by part number: 86624169
|
| 25. |
ZA105122
|
[2] |
ARM
|
IH
- latch rod
|
| 26. |
ZA250536
|
[2] |
YOKE
|
IH
- latch rod Superseded by part number: 87312625
|
| 27. |
180177
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
- hex, 1/2 NC x 1-1/2 inch Superseded by part number: 113-410
|
| 28. |
9413967
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 86992215
|
| 29. |
407210R1
|
[2] |
CLIP
|
IH
PIN - hair (Package of 20)
|
| 30. |
ZA105126
|
[1] |
PIN
|
IH
ASSEMBLY - arm, left (Shown) Superseded by part number: 700120079
|
| 30. |
ZA105125
|
[1] |
PIN
|
IH
ASSEMBLY - arm, right Superseded by part number: 700120082
|
| 31. |
180124
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
|
| 32. |
614452R1
|
[4] |
WASHER
|
IH
- flat, 13/32 x 1-1/4 x 3/32 inch (10 x 32 x 2 mm) Superseded by part number: 86625257
|
| 33. |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 34. |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
