| 42. |
ZA105132
|
[2] |
ROD
|
IH
- latch Superseded by part number: 700120078
|
| 43. |
120371
|
[4] |
NUT,1/2"-20, G5
|
IH
Superseded by part number: 280963
|
| 44. |
ZA105971
|
[1] |
LATCH
|
CAS
ASSEMBLY - tailgate
|
| 45. |
180177
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
- hex, 1/2 NC x 1-1/2 inch Superseded by part number: 113-410
|
| 46. |
21883R1
|
[4] |
WASHER
|
IH
- flat, 17/32 x 1-3/4 x 3/32 inch (13 x 44 x 2 mm) Superseded by part number: 632076R1
|
| 47. |
120396
|
[8] |
WASHER
|
IH
- flat, 17/32 x 1-1/16 x 5/64 inch (13 x 27 x 2 mm) Superseded by part number: 495-11053, 495-11053, NLS
|
| 48. |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 49. |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 50. |
ZA761370
|
[2] |
SPRING
|
IH
ASSEMBLY - extension
|
| 51. |
1281009C1
|
[1] |
INSERT
|
IH
- spring
|
| 53. |
20601R1
|
[2] |
WASHER
|
IH
- flat, 17/32 x 1-1/4 x 7/64 inch (13 x 32 x 3 mm) Superseded by part number: 495-81287
|
| 54. |
Q822
|
[2] |
BOLT
|
IH
- hex, 1/2 NC x 5-1/2 inch Superseded by part number: 1980713C1
|
| 55. |
ZA104551
|
[2] |
PIN
|
IH
- clevis
|
| 56. |
ZA105060
|
[2] |
CLIP
|
IH
BRACKET - offset
|
| 57. |
180124
|
[4] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
- hex, 3/8 NC x 1-1/4 inch Superseded by part number: 88011
|
| 58. |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 59. |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 63. |
1337296C1
|
[2] |
SPACER
|
CAS
- 21/32 ID x 1-1/16 inch (17 x 27 mm) Superseded by part number: 700120067
|
| 64. |
426-1040
|
[2] |
BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 8
|
CAS
- hex, 5/8 NC x 2-1/2 inch Superseded by part number: 280233
|
| 65. |
23276R1
|
[2] |
WASHER
|
IH
- flat, 21/32 x 2 x 5/32 inch (17 x 51 x 4 mm) Superseded by part number: 495-81030
|
| 66. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 67. |
280374
|
[2] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
- hex, 5/8 inch NC
|
| 68. |
96339C1
|
[2] |
CAMSHAFT BEARING,0.3752" ID x 1.25" OD x 0.8025"
|
IH
FOLLOWER - cam, crowned
|
| 69. |
24621R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 8
|
IH
Superseded by part number: 326-636
|
| 72. |
359783C1
|
[2] |
LOCK NUT
|
IH
- hex lock, 3/8 inch NC, Grade 8 Superseded by part number: 88902
|
| 73. |
ZA105108
|
[2] |
BAR
|
IH
STIFFENER - latch
|
| 74. |
180175
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
- hex, 1/25 NC x 1-1/4 inch Superseded by part number: 113-417
|
| 75. |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
- flat, 17/32 x 1-1/16 x 5/64 inch (13 x 27 x 2 mm)
|
