| 1. |
924137R1
|
[2] |
NUT
|
IH
- wing lock, 5/16 inch NC
|
| 2. |
120393
|
[2] |
BEARING WASHER,5/16", SAE
|
IH
WASHER - flat, 11/32 x 11/16 x 1/16 inch (9 x 17 x 2 mm) Superseded by part number: 28588R1
|
| 3. |
1254042C1
|
[2] |
SPRING
|
IH
- compression
|
| 4. |
598807R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 2", Gr 5
|
IH
BOLT - round head square neck, 5/16 NC x 2 inch Superseded by part number: 280618
|
| 5. |
ZA105436
|
[1] |
BAR
|
CAS
- twine tensioner
|
| 6. |
ZA105437
|
[1] |
PLATE
|
CAS
- backup, tensioner
|
| 7. |
ZA105968
|
[2] |
DOOR
|
CAS
- twine box
|
| 8. |
299402C1
|
[4] |
CLAMP
|
IH
CLIP - hinge Superseded by part number: 86010402
|
| 9. |
598802R1
|
[1] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 3/4", G5, Full Thd
|
IH
BOLT - round head square neck, 5/16 NC x 3/4 inch Superseded by part number: 280497
|
| 10. |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 11. |
120376
|
[1] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 12. |
188029C1
|
[4] |
LATCH
|
IH
FASTENER - panel Superseded by part number: 264552
|
| 15. |
ZA104248
|
[1] |
BRACKET
|
IH
- tensioner bar
|
| 16. |
495967R1
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
|
IH
BOLT - round head square neck, 3/8 NC x 1 inch Superseded by part number: 80280503
|
| 17. |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 18. |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 19. |
96316C1
|
[4] |
GUIDE
|
IH
- twine
|
| 20. |
ZA104538
|
[2] |
BRACKET
|
IH
- twine guide
|
| 21. |
ZA105184
|
[1] |
PLATE
|
IH
- end, right
|
| 22. |
REF
|
[1] |
INSTRUCTION
|
NH
DECAL - danger, keep away from pickup and belts (See Page 69)
|
| 23. |
ZA105185
|
[1] |
PLATE
|
IH
- end, left
|
| 27. |
ZA105955
|
[1] |
SHIELD
|
CAS
- top
|
| 28. |
21737R1
|
[2] |
BOLT,Sq Nk, 5/16" - 18 x 5/8", Gr 2
|
IH
- round head short square neck, 5/16 NC x 5/8 inch, Grade 1 Superseded by part number: 598802R1
|
| 32. |
ZA105986
|
[1] |
COVER
|
CAS
- twine box
|
| 33. |
ZA104539
|
[1] |
BRACKET
|
IH
- twine box, right
|
| 34. |
ZA105189
|
[1] |
BRACKET
|
IH
- twine box, left
|
| 36. |
ZA104481
|
[5] |
DIVIDER
|
IH
- twine box
|
