久保田零件查询T10102 HYD.CYLINDER CAP [COMPONENT PARTS] ## S.No.:B1550E;10391 TO 10486, B1550D;52017 TO 52490, B1750E;10347 TO 10396, B1750D;52278 TO 53635 HYDRAULIC SYSTEMEPC Kubota online
广数供应链运营团队, 14 02月, 2025，浏览：
177 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6641636405
|
[1] |
ASSY CAP CYLINDER
|
3.7840(lbs); 1.720
|
| 030. |
6795036240
|
[1] |
SHAFT ADJUSTING
|
0.0990(lbs); 0.045
|
| 040. |
6795036250
|
[1] |
LEVER
|
0.0880(lbs); 0.040
|
| 050. |
6795036260
|
[1] |
PLUG
|
0.1540(lbs); 0.070
|
| 060. |
0481100110
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 070. |
6795036270
|
[1] |
SPRING SET
|
0.0220(lbs); 0.010
|
| 080. |
0481000180
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 090. |
6795036280
|
[1] |
VALVE
|
0.0132(lbs); 0.006
|
| 100. |
6795036290
|
[1] |
POPPET
|
0.0264(lbs); 0.012
|
| 110. |
6795036320
|
[2] |
SPRING RETURN
|
0.0044(lbs); 0.002
|
| 120. |
0401350060
|
[1] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 130. |
0461100140
|
[1] |
CIR CLIP INTERNAL
|
0.0022(lbs); 0.001
|
| 140. |
0541100536
|
[2] |
PIN SPRING
|
0.0066(lbs); 0.003
|
| 150. |
0131110614
|
[1] |
BOLT HEX-SOC-HD
|
0.0044(lbs); 0.002
|
| 160. |
6641636860
|
[1] |
PLUG SCREW
|
0.0022(lbs); 0.001
|
