斗山零件查询HINGE GROUP-FOR VOLVO 440 PLUS Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
738 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
K1021415
|
[-] |
HINGE GROUP
|
|
| 1. |
K1022621
|
[2] |
CYLINDER;BOOM
|
|
| 10. |
K1021419
|
[1] |
PEDAL ASS'Y
|
|
| 11. |
K1021433
|
[1] |
COVER(L.H)
|
|
| 12. |
K1021434
|
[1] |
COVER(R.H)
|
|
| 13. |
K1021430
|
[2] |
HOUSING
|
|
| 14. |
K1021431
|
[2] |
STAY
|
|
| 15. |
K1021432
|
[2] |
BRACKET
|
|
| 2. |
K1022644
|
[2] |
CYLINDER;BUCKET
|
|
| 3. |
K1021407
|
[2] |
PIN
|
|
| 4. |
K1021408
|
[2] |
PIN
|
|
| 5. |
K1021412
|
[2] |
PIN
|
|
| 6. |
K1021409
|
[2] |
PIN
|
|
| 7. |
K1021416
|
[2] |
PIN
|
|
| 8. |
K1021417
|
[4] |
PIN
|
|
| 9. |
K1021418
|
[4] |
PIN
|
|
