神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-037) - RADIATOR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
999 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-1. | VI8970331170 | [1] | RADIATOR ASM. | |
| 1-1. | VI5892140920 | [1] | RADIATOR ASH. | |
| 2. | VI9214506030 | [1] | CAP ASH,RAD. | |
| 3. | VI9099142090 | [1] | HOSE,VINYL,L=850 | |
| 3. | VI8944698820 | [1] | HOSE,VINYL,L=850 | |
| 4. | VI9098090980 | [1] | PLUG,DRAIN | |
| 4. | VI9892142040 | [1] | PLUG,DRAIN | |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONFAN GUIDE |
| 5-1. | NSS | [1] | NOT SOLD SEPARAT | CONFAN GUIDE |
| 5-1. | VI8944698790 | [1] | FAN GUIDE | |
| 6-1. | VI9019008160 | [6] | BOLT,SEMS.FAN GUIDE | |
| 6-1. | VI8944698920 | [6] | BOLT,SEMS,FAN GUIDE | |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONGUARD,FAN |
| 8. | VI8944698870 | [1] | GUARD,FAN | |
| 9. | VI9019008160 | [4] | BOLT,SEMS,FAN GUARD | |
| 10. | NSS | [4] | NOT SOLD SEPARAT | CONCUSHION,RUBBER,RAD. |
| 10. | VI8944698840 | [4] | CUSHION,RUBBER,RAD. | |
| 13. | VI8970247110 | [1] | HOSE,SUCTION RADIATOR | |
| 13-1. | VI8943403900 | [1] | HOSE,WATER,TOP | |
| 14. | VI8970247120 | [1] | HOSE,DELIVERY RADIATOR | |
| 14. | VI8943413620 | [1] | HOSE,WATER,BOTTON | |
| 17. | VI9099155121 | [3] | CLIP | KOBCLIP,HOSE,RADIATOR D=48 |
| 17. | VI5097040490 | [3] | CLIPIHOSE.RADIATOR D=48 | |
| 18. | VI9099150421 | [1] | CLIP,HOSE.RADIATOR D=42 | |
| 18. | VI5097040471 | [1] | CLIP ,HOSE, RADIATOR DM2 | |
| 25. | VI5214800100 | [1] | TANK ASH,RESERVE | |
| 26. | VI8970410220 | [1] | HANGER,RESERVE TANK | |
| 30. | VI8944409690 | [1] | TANK ASH,SURGE | |
| 31. | VI8944493630 | [1] | CAP,SURGE TANK | |
| 32. | VI5824800020 | [1] | SWITCH,LEVEL | |
