约翰迪尔零件查询20``STD - ATTACHMENTS DISC BLADE 20`` HEAD SEGMENTAL NO CARBIDE ( 62001 - 64149) 4544-010/10 [4544-010/10]EPC John Deere online
广数供应链运营团队, 14 02月, 2025，浏览：
376 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700547600
|
[1] |
DISC BLADE, BOLT-ON
|
|
| 2. |
700547400
|
[4] |
TOOTH R.H.
|
|
| 3. |
700547300
|
[4] |
TOOTH L.H.
|
|
| 4. |
700547700
|
[1] |
DISC
|
|
| 5. |
700546300
|
[8] |
Tooth
|
|
| 6. |
700462000
|
[2] |
TIP - CARBIDE
|
|
| 7. |
700544000
|
[32] |
Retainer
|
|
| 8. |
700544100
|
[32] |
Retainer
|
|
| 9. |
810511700
|
[32] |
LOCKNUT 1/2-20UNF
|
|
| 10. |
700348600
|
[32] |
CAPSCREW
|
|
| 15. |
700767400
|
[8] |
TOOTH L.H.
|
|
| 16. |
700767500
|
[8] |
TOOTH R.H.
|
|
| 17. |
700612900
|
[1] |
SOLDER
|
|
| 18. |
700615900
|
[1] |
FLUX
|
|
| |
|
|
NOTE 1: ITEMS ARE USED TO ATTACH
|
|
| |
|
|
CARBIDE TIPS
|
|
| |
|
|
NOTE 2: TO ENSURE PROPER OPERATION OF
|
|
| |
|
|
THE SAW BLADE, TOOTH SEGMENTS
|
|
| |
|
|
SHOULD ALWAYS BE REPLACED AS A
|
|
| |
|
|
COMPLETE SET. EXAMPLE: 4 L.H
|
|
| |
|
|
AND 4 R.H
|
|
