约翰迪尔零件查询20``STD - ATTACHMENTS DISC BLADE 20`` HEAD SEGMENTAL CARBIDE ( 62001 - 64149) 4544-011/10 [4544-011/10]EPC John Deere online
广数供应链运营团队, 14 02月, 2025，浏览：
549 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| A. |
700547800
|
[1] |
Blade
|
|
| 2. |
700548000
|
[4] |
SEGMENT
|
|
| 3. |
842709900
|
[4] |
TIP - CARBIDE
|
|
| 4. |
700462200
|
[4] |
WEAR STRIP
|
|
| 7. |
700544000
|
[32] |
Retainer
|
|
| 8. |
700544100
|
[32] |
Retainer
|
|
| 9. |
810511700
|
[32] |
LOCKNUT 1/2-20UNF
|
|
| 10. |
700348600
|
[32] |
CAPSCREW
|
|
| 11. |
700548100
|
[4] |
SEGMENT - INCL. ITEMS 3 AND 4
|
|
| 12. |
700547900
|
[1] |
DISC
|
|
| 13. |
700544200
|
[8] |
RAKER
|
|
| 14. |
700462000
|
[2] |
TIP - CARBIDE
|
|
| 20. |
700612900
|
[1] |
SOLDER - 1.18 OZ
|
|
| 21. |
700615900
|
[1] |
FLUX - 1LB
|
|
