| 1. |
ZA104460
|
[1] |
ROLLER
|
IH
(No. 14)
|
| 2. |
ZA105023
|
[6] |
BLADE
|
IH
SCRAPER
|
| . . |
16897R1
|
[12] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT - round head, square neck, 5/16 NC x 3/4 inch Superseded by part number: 412-512
|
| . . |
12872R1
|
[12] |
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
|
IH
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd Superseded by part number: 598803R1
|
| 3. |
ZA105026
|
[3] |
BRACKET
|
IH
|
| 4. |
21448R1
|
[40] |
WASHER
|
CAS
- flat, 11/32 x 7/8 x 3/32 inch (8 x 22 x 2 mm) Superseded by part number: 495-81253
|
| 5. |
ZA105030
|
[3] |
DIVIDER
|
IH
- (For 4-3/4 inch wide belts) (Prior to P.I.N. 001179)
|
| 5. |
ZA105297
|
[3] |
DIVIDER
|
IH
- (For 11 inch wide belts) (P.I.N. 001180 and after)
|
| 6. |
ZA105025
|
[3] |
BRACKET
|
IH
|
| 7. |
ZA105010
|
[3] |
ROLLER
|
IH
(No. 9, 11 and 13) Superseded by part number: 228695A1, 228681A1
|
| 8. |
1017954R1
|
[6] |
PLUG,Cap, .485" OD
|
IH
- cap Superseded by part number: 87644289
|
| 9. |
ZA105038
|
[3] |
BLOCK
|
IH
- adjusting left
|
| . . |
180081
|
[6] |
BOLT,Hex, 5/16"-18 x 1 1/4", G5
|
IH
hex, 5/16"-18 NC x 1-1/4", grade 5 Superseded by part number: 179820
|
| 10. |
ZA105037
|
[3] |
BLOCK
|
IH
- adjusting right
|
| 11. |
ZA105045
|
[7] |
COLLAR
|
IH
- bearing
|
| 12. |
1415467R91
|
[6] |
BALL BEARING,35 mm ID x 72 mm OD x 17 mm
|
IH
- 1.378 inch ID (35 mm) Superseded by part number: 84002007
|
| 13. |
ZA105012
|
[1] |
ROLLER
|
IH
(No. 12) Superseded by part number: 228685A1, 228695A1
|
| 14. |
ZA271276
|
[1] |
SPRING
|
IH
|
| 15. |
ZA201085
|
[1] |
INSERT
|
IH
PLUG - lift spring
|
| 16. |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 17. |
750832R1
|
[1] |
BOLT
|
IH
- hex, 1/2 NC x 4-1/2 inch
|
| 18. |
180193
|
[1] |
BOLT,Hex, 1/2" - 13 x 3 3/4", Gr 5
|
IH
- hex, 1/2 NC x 3-3/4 inch Superseded by part number: 113-450
|
| 19. |
ZA104215
|
[1] |
ARM
|
IH
|
| . . |
180183
|
[1] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5
|
IH
- hex, 1/2 NC x 2-1/4 inch Superseded by part number: 113-441
|
| 20. |
27342R1
|
[1] |
WASHER
|
IH
WASHER - flat, 17/32 x 1 x 1/16 inch (13 x 25 x 1 mm) Superseded by part number: 495-81254
|
| 21. |
9413956
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT - hex lock, 1/2 inch NC Superseded by part number: 231-4138
|
| 22. |
ZA103001
|
[1] |
PULLEY
|
IH
SHEAVE - belt idler
|
| 23. |
26316R1
|
[3] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
IH
- hex lock, 1/2 NC x 1 inch Type 8 Superseded by part number: 113-451
|
| 24. |
357020R1
|
[3] |
WASHER
|
IH
- flat, 17/32 x 1-3/4 x 1/4 inch (13 x 44 x 6 mm)
|
| 25. |
ZA105052
|
[1] |
PULLEY
|
IH
SHEAVE - speed up (Interchangeable with ZA104246)
|
| 25. |
ZA104246
|
[1] |
PULLEY
|
IH
SHEAVE - slow down (Interchangeable with ZA105052)
|
| 26. |
ZA104593
|
[4] |
HUB
|
IH
- splined
|
| 27. |
ZA104226
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET - 24 tooth
|
| . . |
113-257
|
[4] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
|
CAS
- hex, 3/8 NC x 2-1/2 inch Superseded by part number: 87936
|
| 28. |
96328C1
|
[3] |
BALL BEARING,40mm ID x 80mm OD x 22mm W
|
CAS
- 1.5753 inch ID (40 mm)
|
| 29. |
ZA104841
|
[2] |
HOUSING
|
IH
- bearing
|
| . . |
18684R1
|
[5] |
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
|
IH
- round head, square neck, 3/8 NC x 1-1/4 inch Superseded by part number: 550796R1
|
