| 30. |
120394
|
[10] |
WASHER,3/8", SAE
|
IH
WASHER - flat, 13/32 x 13/16 x 1/16 inch (10 x 20 x 1 mm) Superseded by part number: 87016
|
| 31. |
ZA103192
|
[1] |
SPRING
|
IH
- tension
|
| 32. |
432-1220
|
[1] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Pin, Split (Cotter), 3/16" x 1 1/4" Superseded by part number: 87398
|
| 33. |
446257
|
[2] |
WASHER,3/4" x 1 3/4" x .148"
|
IH
- flat, 13/16 x 1-3/4 x 1/8 inch (20 x 44 x 3 mm) Superseded by part number: 495-31081
|
| 34. |
ZA103344
|
[1] |
BRACKET
|
IH
TIGHTENER - arm
|
| . . |
271724
|
[1] |
PIN,Hex, 5/8" - 11 x 2 1/4", Gr 5
|
NNA
- hex, 5/8 NC x 2-1/4 inch Superseded by part number: 413-1036, 413-1036, NLS
|
| 35. |
23836R1
|
[4] |
WASHER
|
IH
- flat, 21/32 x 1-3/8 x 7/64 inch (16 x 34 x 2 mm) Superseded by part number: 5122064
|
| 36. |
ZA104624
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET - 42 teeth Superseded by part number: 700120248
|
| . . |
180137
|
[4] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
|
IH
- hex, 3/8 NC x 2-3/4 inch Superseded by part number: 113-248
|
| 37. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
- idler
|
| 38. |
9413960
|
[1] |
LOCK NUT,5/8"-11, GB
|
IH
NUT - hex lock, 5/8 inch NC Superseded by part number: 85700693
|
| 39. |
ZA103341
|
[1] |
BUSHING
|
IH
|
| 40. |
ZA105055
|
[1] |
HOUSING
|
IH
- pivot left
|
| . . |
180081
|
[6] |
BOLT,Hex, 5/16"-18 x 1 1/4", G5
|
IH
hex, 5/16"-18 NC x 1-1/4", grade 5 Superseded by part number: 179820
|
| 41. |
ZA105013
|
[1] |
ROLLER
|
IH
(No. 10) Superseded by part number: 47442495, 700709834, ZA105795
|
| 42. |
180192
|
[6] |
BOLT (SPREADER),Hex, 1/2" - 13 x 3 1/2", Gr 5
|
IH
BOLT - hex, 1/2 NC x 3-1/2 inch Superseded by part number: 179895
|
| 43. |
120378
|
[6] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 44. |
ZA104412
|
[33] |
BELT,4.75" W 73.22" L
|
IH
4.75" W x 73.22" L, Top endless (Prior to P.I.N. 001179)
|
| 44. |
ZA105005
|
[15] |
BELT
|
IH
- top endless (11 inch wide) (P.I.N. 001180 and after) Superseded by part number: 700709544
|
| 45. |
ZA104107
|
[33] |
BELT
|
IH
- Top (4-3/4 inch wide) (Prior to P.I.N. 001179)
|
| 45. |
ZA105003
|
[15] |
BELT
|
IH
- Top (11 inch wide) (P.I.N. 001180 and after) Superseded by part number: 700724731
|
| 46. |
ZA102971
|
[33] |
PIN
|
IH
(For 4-3/4 inch wide belt) (Prior to P.I.N. 001179)
|
| 46. |
ZA102977
|
[15] |
PIN
|
IH
(For 11 inch wide belt) (P.I.N. 001180 and after)
|
| 47. |
ZA105054
|
[1] |
HOUSING
|
IH
- pivot right
|
| 48. |
ZA104227
|
[5] |
SPROCKET ASSY.
|
IH
SPROCKET - 30 teeth
|
| . . |
180130
|
[16] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
IH
- hex, 3/8 NC x 2 inch Superseded by part number: 113-219
|
| 49. |
ZA304776
|
[3] |
SLIDE
|
IH
- chain Superseded by part number: 700709424
|
| . . |
27464R1
|
[3] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 4", Gr 5
|
IH
BOLT - round head, square neck, 1/2 NC x 4 inch Type 5 Superseded by part number: 87495288
|
| 50. |
NSS
|
[3] |
NOT SOLD SEPARAT
|
CON
CHAIN (Use 121 links from roll marked 611362R91, 1 offset link 612612R91 and 1 connecting link 574532R91)
|
| . . |
611362R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - 10 foot (3.048 m) roll Superseded by part number: 611362R91X
|
| . . |
612612R91
|
[1] |
CHAIN LINK
|
IH
LINK - offset Superseded by part number: 241-1716
|
| . . |
574532R91
|
[1] |
CLIP, SPRING
|
IH
LINK - connecting Superseded by part number: 241-1316
|
| 51. |
22822R1
|
[8] |
WASHER
|
IH
- flat, 1-21/32 x 2-1/2 x 3/32 inch (42 x 63 x 2 mm) Superseded by part number: L31792
|
| 52. |
462182R91
|
[1] |
BEARING, BALL,40mm ID x 90mm OD x 23mm W
|
IH
BEARING - 1.5753 inch ID (40 mm) Superseded by part number: 913716
|
| 53. |
ZA104589
|
[1] |
HOUSING
|
IH
- bearing Superseded by part number: 700120233
|
| . . |
18684R1
|
[5] |
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
|
IH
- round head, square neck, 3/8 NC x 1-1/4 inch Superseded by part number: 550796R1
|
| 54. |
26317R1
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 8
|
IH
- hex lock, 1/2 NC x 1-1/4 inch Type 8
|
| . . |
208790C1
|
[1] |
PACKAGE
|
IH
KIT - belt repair (Box of lacing hooks)
|
| . . |
124050C1
|
[1] |
|
P
LACER - belt (6 inch)
|
