神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-059) - GENERATOR (HITACHI) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
198 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8943380960 | [1] | GENERATOR ASM,12V-45A | |
| 1. | VI8943892450 | [1] | ROTOR ASM. | |
| 2. | VI8943892420 | [1] | BEARING,BALL | |
| 3. | VI8943892460 | [1] | STATOR ASM. | |
| 4. | VI8943892320 | [1] | COVER ASH.IREAR | |
| 5. | VI8943892330 | [1] | COVER,REAR | |
| 6. | VI8943892340 | [1] | REGULATOR ASM,BRUSH | |
| 7. | VI8944628500 | [1] | BRUSH SET | |
| 8. | VI8943892350 | [1] | GUIDE,FAN | |
| 9. | VI8943892360 | [1] | DIODE ASM. | |
| 10. | VI8943892370 | [1] | CONDENSER ASM. | |
| 11. | VI8943892430 | [1] | BOLT | |
| 12. | VI8943892440 | [1] | BOLT | |
| 13. | VI8943892380 | [1] | COVER ASM,FRONT | |
| 14. | VI8943892390 | [1] | RETAINER,BEAR ING | |
| 15. | VI8943892410 | [1] | BEAR ING,BALL | |
| 16. | VI8944103450 | [1] | SCREW KIT | |
| 17. | VI8943892400 | [1] | PULLEY | |
| 18. | VI5812191890 | [2] | BOLT,THROUGH | |
| 19. | VI8944243730 | [1] | BOLT,THROUGH | |
| 20. | VI8944103440 | [1] | NUT SET,PULLEY | |
