神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-060) - GENERATOR (HITACHI) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
608 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8970232630 | [1] | GENERATOR | KOBASM,24V-40A Superseded by part number: VI8970232631 |
| 3. | VI8970371670 | [1] | ROTOR ASM. | |
| 5. | VI8970371680 | [1] | STATOR | KOBASM. |
| 7. | VI8970371700 | [1] | COVER ASM,REAR | |
| 8. | VI8970371710 | [1] | COVER | KOBREAR |
| 9. | VI8970371720 | [1] | REGULATOR | KOBREGURATOR ASM,BRUSH |
| 12. | VI8970371730 | [1] | BRUSH SET | KOB |
| 13. | VI5812510160 | [1] | REGULATOR | KOBREGURATOR ASM,I.C |
| 14. | VI8970371740 | [1] | DIODE | KOBDIODE ASM. |
| 17. | VI8970371690 | [1] | COVER | KOBASM,FRONT Superseded by part number: VI8941164330 |
| 18. | VI8942239740 | [1] | RETAINER,BEARING | |
| 19. | VI8941430300 | [1] | PULLEY | KOBASM. |
| 22. | VI8941164350 | [4] | BOLT,THROUGH | |
| 24. | VI8970371750 | [1] | NUT,PULLEY | |
| 26. | VI8944628590 | [1] | BEARING,BALL | |
| 27. | VI8943335210 | [1] | BEARING HALF | KOBBEARING,BALL |
| 28. | VI8942336530 | [1] | SCREW KIT | |
| 30. | VI8970378870 | [2] | BOLT | |
