凯斯零件查询(3650) - CASE IH ROUND TIE BALER (1/84-12/88) (72) - TWINE BOX, ELECTRIC TIE BALERS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
891 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
924137R1
|
[2] |
NUT
|
IH
- wing
|
| 2. |
611344R1
|
[2] |
WASHER
|
IH
- flat, 11/32 x 7/8 x 1/16 inch (8 x 22 x 1 mm) Superseded by part number: 495-61034
|
| 3. |
1254042C1
|
[2] |
SPRING
|
IH
|
| 5. |
188029C1
|
[4] |
LATCH
|
IH
FASTERNER - camlock Superseded by part number: 264552
|
| 7. |
299402C1
|
[4] |
CLAMP
|
IH
Superseded by part number: 86010402
|
| 8. |
ZA104483
|
[2] |
DOOR
|
IH
|
| 11. |
96316C1
|
[4] |
GUIDE
|
IH
- rope
|
| 12. |
ZA104248
|
[1] |
BRACKET
|
IH
|
| 13. |
ZA105189
|
[1] |
BRACKET
|
IH
|
| 14. |
ZA104781
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - danger
|
| 15. |
ZA104481
|
[4] |
DIVIDER
|
IH
|
| 16. |
ZA104459
|
[1] |
BRACKET
|
IH
|
| 17. |
ZA105185
|
[1] |
PLATE
|
IH
ENDPLATE - left
|
| 18. |
ZA104136
|
[1] |
DECAL
|
CAS
- danger
|
| 19. |
ZA104247
|
[1] |
COVER
|
IH
- twine box
|
| 20. |
ZA104538
|
[1] |
BRACKET
|
IH
ENDPLATE - right
|
| 22. |
ZA104539
|
[1] |
BRACKET
|
IH
- right
|
| 23. |
A105437
|
[1] |
TENSIONER (Replaces ZA105168) (Also order ZA105437)
|
|
| 24. |
ZA105436
|
[1] |
BAR
|
CAS
BACKUP - tensioner
|
