| 1. |
ZA105101
|
[1] |
HARNESS
|
IH
|
| . . |
3118918R1
|
[1] |
FUSE
|
IH
- 3 AG 5 amperes
|
| 2. |
299402C1
|
[7] |
CLAMP
|
IH
Superseded by part number: 86010402
|
| 3. |
ZA104483
|
[2] |
DOOR
|
IH
|
| . . |
598806R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1 3/4", Gr 5
|
IH
BOLT - round head, square neck, 5/16 NC x 1-3/4 inch Type 5 Superseded by part number: 86508771
|
| 4. |
ZA105436
|
[1] |
BAR
|
CAS
TENSIONER (Replaces ZA105168) (Also order backup ZA105437)
|
| 5. |
1254042C1
|
[2] |
SPRING
|
IH
|
| 6. |
611344R1
|
[1] |
WASHER
|
IH
- flat, 11/32 x 7/8 x 1/16 inch (8 x 22 x 1 mm) Superseded by part number: 495-61034
|
| 7. |
924137R1
|
[2] |
NUT
|
IH
- wing
|
| 8. |
96316C1
|
[1] |
GUIDE
|
IH
- rope
|
| 9. |
ZA732614
|
[1] |
RING, SNAP
|
IH
RING - retaining
|
| 10. |
ZA732613
|
[1] |
LENS
|
IH
- amber
|
| 11. |
ZA105024
|
[1] |
LIGHT
|
IH
INDICATOR
|
| 12. |
ZA732615
|
[1] |
GASKET
|
IH
|
| 13. |
ZA105102
|
[1] |
BRACKET
|
IH
- right
|
| 14. |
ZA105184
|
[1] |
PLATE
|
IH
ENDPLATE - right
|
| 15. |
ZA104136
|
[1] |
DECAL
|
CAS
- danger
|
| 16. |
291207C1
|
[5] |
CLAMP
|
IH
TIE - hose Superseded by part number: 529070
|
| 17. |
ZA104481
|
[4] |
DIVIDER
|
IH
|
| 18. |
ZA104459
|
[1] |
BRACKET
|
IH
|
| 19. |
ZA104248
|
[1] |
BRACKET
|
IH
|
| 20. |
ZA104247
|
[1] |
COVER
|
IH
- twine box
|
| 21. |
ZA105185
|
[1] |
PLATE
|
IH
ENDPLATE - left
|
| 23. |
ZA105189
|
[1] |
BRACKET
|
IH
|
| 24. |
ZA104781
|
[1] |
PRODUCT GRAPHIC
|
IH
DECAL - danger
|
| 25. |
ZA105100
|
[1] |
HARNESS
|
IH
|
| 26. |
127979
|
[2] |
GROMMET,3/4" ID x 1 3/8" x .062", Diag Cut
|
IH
- harness Superseded by part number: 248-1220
|
| 27. |
ZA105068
|
[1] |
BRACKET
|
IH
- switch (Prior to P.I.N. 000525)
|
| 28. |
ZA104641
|
[1] |
SWITCH
|
IH
- (Prior to P.I.N. 000525)
|
| . . |
436668
|
[2] |
|
P
SCREW - an head slotted, No. 6 x 7/8 inch
|
| . . |
134530
|
[2] |
NUT,Hex, #6 - 32
|
IH
Machine screw #6-32 Superseded by part number: 88458
|
| . . |
131044
|
[2] |
LOCK WASHER
|
IH
Lock, #6 Superseded by part number: 492-11006
|
| . . |
2730R1
|
[1] |
WASHER - flat, 5/32 x 3/8 x 1/32 inch (3 x 9 x 1 mm)
|
|
| 29. |
ZA104538
|
[2] |
BRACKET
|
IH
|
| 30. |
188029C1
|
[4] |
LATCH
|
IH
FASTENER - camlock Superseded by part number: 264552
|
| 31. |
ZA104562
|
[1] |
COVER
|
IH
BRACKET - switch (P.I.N. 000526 and after) Superseded by part number: 230414A1
|
| 32. |
ZA103633
|
[1] |
SWITCH
|
IH
(P.I.N. 000526 and after) Superseded by part number: 232773A1
|
| . . |
120221
|
[2] |
NUT,Sl Rnd Hd, #10 - 24 x 1/2"
|
IH
SCREW - round head, slotted, No. 10 x 1/2 inch Superseded by part number: 159920
|
| . . |
26303R1
|
[2] |
HARDWARE,#10-24
|
IH
NUT - machine screw, No. 10 Superseded by part number: 3062835R1
|
| . . |
120217
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| . . |
120391
|
[1] |
WASHER,#10
|
IH
- flat, 7/32 x 1/2 x 1/32 inch (5 x 12 x 1 mm) Superseded by part number: 9824326
|
| 33. |
ZA105437
|
[1] |
PLATE
|
CAS
BACKUP - tensioner
|
