神钢零件查询(4JB1) - ISUZU DIESEL ENGINE - K903C EXCAVATOR (1/06-12/07) (01-013[01]) - AIR CLEANER & OTHER PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
663 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5142102130 | [1] | CLEANER ASM., AIR | |
| 6. | VI5142110670 | [1] | BODY ASM., AIR CLEANER | |
| 7. | VI9142191410 | [1] | INDICATOR | |
| 11. | VI5142150140 | [1] | ELEMENT ASM. | |
| 12. | VI9142170620 | [1] | NUT | KOBASM. Superseded by part number: 1142170030 |
| 13. | VI9142171770 | [1] | WASHER | |
| 20. | VI5142120560 | [1] | PAN ASM.; PAN, DUST | |
| 21. | VI5142170040 | [1] | CLAMP ASM. | |
| 25. | VI9142176020 | [2] | BAND, AIR CLEANER | |
| 26. | VI1815300050 | [1] | INDICATOR | |
| 30. | VI9142106540 | [1] | CLEANER ASM., AIR | |
| 31. | VI9142113160 | [1] | BODY ASM., AIR CLEANER | |
| 32. | VI9142192860 | [1] | INDICATOR | |
| 33. | VI9142151670 | [1] | ELEMENT-INNER | |
| 34. | VI9142151660 | [1] | ELEMENT-OUTER | |
| 35. | VI9142170620 | [2] | NUT | KOBASM. Superseded by part number: 1142170030 |
| 36. | VI9142121140 | [1] | BAFFLE ASM. | |
| 37. | VI9142170610 | [1] | CLAMP ASM. | |
| 38. | VI5142300540 | [1] | CAP ASM., AIR CLEANER | |
| 39. | VI5142340590 | [1] | BAND, AIR CLEANER | |
