| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
VOE4924250
|
[0001] |
Engine member
|
V
|
| 3. |
VOE955364
|
[0008] |
Hexagon screw
|
|
| 4. |
VOE941912
|
[0008] |
Spring washer
|
|
| 5. |
VOE751991
|
[0001] |
Engine anchorage
|
LH
|
| 6. |
VOE751992
|
[0001] |
Engine anchorage
|
RH
|
| 1. |
VOE4924249
|
[0001] |
Frame member
|
H SER NO -2166
|
| 7. |
VOE926004
|
[0006] |
Screw
|
|
| 8. |
VOE940280
|
[0010] |
Spring washer
|
|
| 9. |
VOE955563
|
[0002] |
Hexagon screw
|
|
| 10. |
VOE955561
|
[0002] |
Hexagon screw
|
|
| 11. |
VOE4739954
|
[0001] |
Anchorage
|
|
| 12. |
VOE730412
|
[0001] |
Support bearing
|
|
| 13. |
VOE13955366
|
[0004] |
Screw
|
|
| 14. |
VOE13955900
|
[0008] |
Washer
|
|
| 15. |
VOE963110
|
[0004] |
Lock nut
|
|
| 16. |
VOE735137
|
[0001] |
Pin
|
|
| |
VOE4939688
|
[0001] |
Engine member
|
|
| 17. |
VOE13970974
|
[0004] |
Hexagon screw
|
|
| |
|
|
None
|
H SER NO 2167 - 4279
|
| 18. |
VOE60110353
|
[0008] |
Washer
|
|
| 19. |
VOE13971090
|
[0004] |
Lock nut
|
|
| 20. |
VOE735138
|
[0001] |
Lock washer
|
|
| 21. |
VOE13970947
|
[0002] |
Hexagon screw
|
|
| 22. |
VOE941908
|
[0002] |
Spring washer
|
|
| 23. |
VOE4924246
|
[0002] |
Anchorage
|
PROD NO 33100, 33105.
|
| |
VOE4850250
|
[0002] |
Anchorage
|
PROD NO 33106, 33107.
|
| 24. |
VOE13955370
|
[0008] |
Screw
|
|
| 25. |
VOE926199
|
[0004] |
Tab washer
|
PROD NO 33100, 33105.
|
| |
VOE4939688
|
[0001] |
Engine member
|
H SER NO 4280 -
|
| |
VOE13955900
|
[0008] |
Washer
|
PROD NO 33106, 33107.
|
| 26. |
VOE955387
|
[0004] |
Hexagon screw
|
PROD NO 33100, 33105.
|
| |
VOE13955366
|
[0008] |
Screw
|
PROD NO 33106, 33107.
|
| 27. |
VOE955903
|
[0008] |
Plain washer
|
PROD NO 33100, 33105.
|
| |
VOE13955900
|
[0008] |
Washer
|
PROD NO 33106, 33107.
|
| 28. |
VOE963111
|
[0004] |
Lock nut
|
PROD NO 33100, 33105.
|
| |
VOE4954833
|
[0004] |
Nut plate
|
PROD NO 33106, 33107.
|
